X5750 CE ram milling machine

FOB Price

USD $15,074 - $18,971 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Liaoning, China
Brand Name	LFM	Model Number	X5750 ram milling machine
Type	Universal	CNC or Not	Normal
Voltage	220V/380V/415V/440V/480V	Power(W)	7.5kW
Dimension(LWH)	2475x2260x2180mm	Weight	5000kgs
Certification	CE; ISO9001:2008; GB/T19001:2008	Warranty	12 months
After-sales Service Provided	Engineers available to service machinery overseas

X5750 CE ram milling machine

Main Features

Such ram milling machine has following features:

1. high strength HT-200 and high rigidity cast iron of bed;

2. guideways quenched and fine grinded;

3. x, y, z axis automatic feeding driven by servo motors;

4. ballscrew can be ordered specially;

5. CE Standard and CE Certificate;

6. DRO is available, too.

7. X5750 is equal to UWF12B;

Main Technical Data

SPECIFICATIONS	UNIT	X5750 ram milling machine (UWF12B)
Table size	mm	500×1600
T-slots(NO.×width×pitch)	mm	5×18×80
Table travel (X×Y×Z)	mm	1200×700×500
Swivel angle of milling head	-	360°
Spindle taper	-	ISO50
Spindle speed range	r.p.m	(27) 30~2050
Table feed(X/Y/Z)	mm/min	10~1000/10~1000/5~500
Table rapid speed		2200/2200/1100
Distance between spindle nose and table surface	mm	25~525
Distance from spindle center line to column	mm	55~755
Main motor power	kW	7.5
Feed motor	kW	AC servo motor X/Y:15NM; Z: 18NM
Max load	kg	1800
Overall size	mm	2475×2260×2180
weight	kg	5000
