S series CE bed type cnc vertical milling machine
- Dalian/Qingdao China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Catalogue of CE cconomic knee type vertical milling machine
-
Catalogue of vertical turret milling machine for sale
-
XN6330h universal vertical and horizontal milling machine
-
Vertical Turret milling machine with CE
-
S1354B simple bed type cnc vertical milling machine
-
XD30A CE economic cnc vertical milling machine
Product Details
| Condition | New | Place of Origin | Liaoning, China | |
| Brand Name | LFM | Model Number | S1354B/S1654/S2063/S2063A/S2473 cnc vertical milling machine | |
| Type | Vertical | CNC or Not | CNC | |
| Voltage | 220V 380V 400V 415V 440V 480V | Power(W) | 5.5/7.5kW | |
| Dimension(L*W*H) | depends | Weight | 3400~7500kgs | |
| Certification | CE Certificate; ISO9001:2008; GB/T19001:2008 | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
S series CE bed type cnc vertical milling machine
1. Main parts are original from TAIWAN;
2. GERMANY technology, main technology guided by GERMANY engineer;
3. Providing machine as OEM form for GERMANY Company as long term;
4. Full production is supervised by TAIWAN engineers;
5. Strictly according to CHINA National Standard and CE Safety Standar;
6. CE Certificate;
Specifications | Unit | S1354B | S1654 | S2063 | S2063A | S2473 |
Table size (L × W) | mm | 1370×330 | 1370×406 | 1600×510 | 1600×510 | 1854×610 |
Table loading capability | kg | 400 | 800 | 1200 | 1200 | 1500 |
X Travel | mm | 800 | 1000 | 1200 | 1200 | 1500 |
Y Travel | mm | 450 | 480 | 700 | 740 | 740 |
Z Travel | mm | 480 | 600 | 600 | 740 | 700 |
Max. move speed(X/Y/Z) | mm/min | 8000 | 8000 | 10000 | 10000 | 10000 |
Max. feed speed(X/Y/Z) | mm/min | 3000 | 3000 | 4000 | 4000 | 4000 |
Spindle speed range | r/min | 40~6000 | 40~6000 | 40~6000 | 40~6000 | 40~6000 |
Spindle taper |
| BT40 | BT40 | BT40/BT50 | BT40/BT50 | BT40/BT50 |
Spindle motor power | kW | 5.5 | 7.5 | 7.5 | 7.5 | 7.5 |
X/Y/Z servo motor power | kW | 1.5 | 1.5 | 2.8 | 2.8 |
|
Spindle quill diameter | mm | Φ120 | Φ150 | Φ150/Φ155 | Φ150/Φ155 | Φ150/Φ155 |
Distance from spindle nose end face to table surface | mm | 60~640 | 80~680 | 60~660 | 60~800 | 80~780 |
Ball screws (X axis) | mm | Φ32×5 P4 Double nuts | Φ32×5 P4 Double nuts | Φ40×10 P4 Double nuts | Φ40×10 P4 Double nuts | Φ40×10 P4 Double nuts |
Ball screws (Y axis) | mm | Φ32×5 P4 Double nuts | Φ40×5 P4 Double nuts | Φ40×10 P4 Double nuts | Φ40×10 P4 Double nuts | Φ40×10 P4 Double nuts |
Ball screws (Z axis) | mm | Φ32×5 P4 Double nuts | Φ40×5 P4 Double nuts | Φ40×10 P4 Double nuts | Φ40×10 P4 Double nuts | Φ40×10 P4 Double nuts |
Positioning accuracy | mm | 0.025 | 0.03 | 0.03 | 0.03 | 0.04 |
Repeat positioning accuracy | mm | 0.012 | 0.016 | 0.016 | 0.016 | 0.020 |
Packing dimension (Semi-closure guard) (L × W × H) | mm | 2280×2250×2470 | 2500×2280×2650 | 2280×2900×2850 | 2280×2900×2950 | 2280×2900×2950 |
Packing dimension (Full-closure guard) (L × W × H) | mm | 3000×2280×2470 | 3300×2280×2650 | 3700×2800×2870 | 3700×2890×2970 | 4700×2800×2970 |
Machine weight (Semi-closure guard) | kg | 2600 | 3800 | 5000 | 5400 | 5200 |
Machine weight ((Full-closure guard) | kg | 3400 | 4720 | 6400 | 6900 | 7500 |
1. Semi cover(full cover is optional, extra money will be needed)
2. Cutting fluid circulation system
3. Auto lubrication system
4. Spindle air flow
5. Lamp
6. Pause lamp
7. Leveling adjusting screw and block
8. Clamping apparatus
Optional accessories:
1. Spindle from POSA spindle
2. Spindle speed: 8000rpm
3. Lead team lead screw made in Taiwan
4. Full closed safety guard
