Catalogue of CE cconomic knee type vertical milling machine
- Dalian/Qingdao China
- T/T Credit Card PayPal
You May Like
-
Catalogue of vertical turret milling machine for sale
-
XN6330h universal vertical and horizontal milling machine
-
Vertical Turret milling machine with CE
-
S1354B simple bed type cnc vertical milling machine
-
XD30A CE economic cnc vertical milling machine
-
XD-30/40A CE cnc vertical milling machine for heavy machining
Product Details
| Condition | New | Place of Origin | Liaoning, China | |
| Brand Name | LFM | Model Number | X5025 X5028 X5032 X5040 vertical milling machine | |
| Type | Universal | CNC or Not | Normal | |
| Voltage | 220V/380V/415V/440V/480V | Power(W) | 3~11kW | |
| Dimension(L*W*H) | 1680/2550x2150x2290mm | Weight | 1450~4250kgs | |
| Certification | CE; ISO9001:2008; GB/T19001:2008 | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
X50 series knee type vertical milling machine Technical Data
X50 series vertical milling machine has following features:
1. one more powerful metal cutting machine,
2. high rigidity,
3. wide range of spindle feed also can bear a heavy burden.
4. the spindle taper hole can install many kinds of cylindrical cutter, disc cutter, form cutter, end milling cutter and so on,
5. optional accessories as dividing head, rotary table, machine vice,milling chuck, Digital readout, can make such machine more functional.
Main Usage:
6. Suitable for machining all parts plane, inclined plane, groove, hole,keyway, etc,
7. for machinery manufacturing, mould, apparatus, instrument, car and motor car;
Specifications | Unit | X5025 | X5028 | X5032 | X5032B | XL5032 | XL5032C | XL5032CL | X5040 |
Table size | mm | 250×1250 | 280×1200 | 320×1325 | 320×1600 | 320×1325 | 320×1325 | 320 x 1600 | 400 x 1700 |
Table Travel (X/Y/Z) | mm | 680/280/400 | 620/280/400 | 700/680 255/240 370/350 | 900/880 255/240 370/350 | 750/320/460 | 1100/320/450 | 1300/320/450 | 1400/400/515 |
Table feed (X/Y/Z) | mm/min | 20~800/20~800/10~400 | 20~800/20~800 /10~400 | 23.5~1180/23.5~1180/8~394 | 23.5~1180/23.5~1180/8~394 | 30~1200/20~800/15~600 | 30~1200/20~800/15~600 | 30~1200/20~800/15~600 | 30~1200/20~800/15~600 |
Spindle travel | mm | 70 | 70 | 70 | 70 | 70 | 70 | 70 | 85 |
Spindle bore | mm | 29 | 29 | 29 | 29 | 29 | 29 | 29 | 29 |
Spindle taper |
| 7:24 ISO50 | 7:24 ISO50 | 7:24 ISO50 | 7:24 ISO50 | 7:24 ISO50 | 7:24 ISO50 | 7:24 ISO50 | 7:24 ISO50 |
Rapid speed of table(X /Y/Z) | mm/min | 1000/1000/500 | 1000/1000/500 | 2300/1540/770 | 2300/1540/770 | 2300/1540/770 | 2300/1540/770 | 2300/1540/770 | 2300/1540/770 |
T-slots (No./width/pitch) | mm | 3/14/63 | 5/14/50 | 3/18/70 | 3/18/70 | 3/18/70 | 3/18/70 | 3/18/70 | 3/18/70 |
Distance between spindle nose and table | mm | 35~435 | 35~435 | 60~410 | 60~410 | 50~510 | 50~500 | 50~500 | 30~500 |
Distance between spindle and column | mm | 285 | 285 | 350 | 350 | 300 | 300 | 300 | 385 |
Swivel angle of vertical milling head |
| ±30° | ±30° | ±45° | ±45° | ±30° | ±30° | ±30° | ±45° |
Spindle speed range |
| 12Steps | 12Steps | 18Steps | 18Steps | 12Steps | 12Steps | 12Steps | 18Steps |
Spindle speed | rpm | 35~1500 | 35~1500 | 30~1500 | 30~1500 | 50~1475 | 50~1475 | 50~1475 | 30~1500 |
Main motor power | kW | 3 | 3 | 7.5 | 7.5 | 5.5 | 5.5 | 5.5 | 11 |
Rapid motor power | kW | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
Overall size | cm | 168 x 168x 181 | 163 x168 x 181 | 229 x 177 x190 | 229 x 205 x190 | 180x 210 x 215 | 224 x 210x 215 | 252x 210 x 215 | 255x 215 x 229 |
N.W/G.W | kg | 1450 | 1500 | 2900/3200 | 3000/3300 | 2750 | 2850 | 2900 | 4250 |
