CDE6266 Series Economic Conventional Lathe with Gap

FOB Price

US$ 9,129 - 10,558 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	Normal	Automatic Grade	Manual
Max. Swing Diameter	660mm	Place of Origin	Liaoning, China
Brand Name	DALIAN	Model Number	CDE6266A(660x2000~3000mm)
Voltage	3Phx220V 380V 400V 415V 440V 480V, 50/60Hz	Power(W)	5.5/7.5kW
Certification	ISO9001:2008; GB/T19001:2008	After-sales Service Provided	Engineers available to service machinery overseas

CDE6266 Series Economic Lathe

Main Featurers:

Main Usage:

It can machine inner circle, outer circle, and end and head surface, taper surface.
Gap lathe can process the deformation parts.
Function is including the drilling and reaming.
Threads cutting: Metric, inch, diametrical pitch, module thread;

Specifications	Unit	CD6E266Ax2000/2200	CD6E266Ax3000
Max. swing over bed	mm	660	660
Max. swing over carriage	mm	430	430
Max. swing over gap	mm	910	910
Width of gap	mm	394	394
Max. length of work piece	mm	2000/2200	3000
Width of guide way	mm	52	52
Spindle nose		No.6	No.6
Spindle speed	rpm	11~1400/22speeds	11~1400/22speeds
Dia. of spindle bore	mm	0.035~2.842	0.035~2.842
Taper of spindle bore		0.009~0.804	0.009~0.804
Longitudinal feed	mm/rev	0.5~240(66)	0.5~240(66)
Cross feed		80~1/4(49)tpi	80~1/4(49)tpi
Metric thread	mm	0.25~120(57)	0.25~120(57)
Inch thread		160-7-16DP(50)	160-7-16DP(50)
Module thread	mm	25×25	25×25
Diametrical pitch thread		150	150
Max. travel of cross slide	mm	393	393
Travel of top slide	mm	12	12
Travel of tailstock quill	mm	150	150
Diameter of tailstock quill	mm	75	75
Taper bore of tailstock quill		No.5	No.5
Main motor power		7.5kW(50Hz) 5.5kW(60Hz)	7.5kW(50Hz) 5.5kW(60Hz)
Wooden box/Pallet packing	mm	395x115x190 383x112x179	495x115x190 483x112x179
Packing & Weight	kgs	3053/2338	3393/2698
