Bench lathe LFM6132A 1 phase/3 phase
- Dalian China
- T/T Credit Card PayPal
You May Like
-
Large Spindle Bore Lathe- spindle hole 200mm
-
Smaller Economic High-speed Universal Gap Lathe
-
Catalogue of CDL Series high presion manual metal lathe machine for sale
-
CW6280Ex2000 conventional horizontal lathe machine
-
CW6280Ex750 universal horizontal lathe machine
-
105/130mm Large Spindle Bore Horizontal GAP Lathe Hot-sale CW6280E
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | Normal | Automatic Grade | Manual | |
| Max. Swing Diameter | 320mm | Place of Origin | Liaoning, China | |
| Brand Name | Dalian | Model Number | LFM6132A | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Bench lathe Parameter
It can machine inner circle, outer circle, and end and head surface, taper surface. Gap lathe can process the deformation parts. Function is including the drilling and reaming. Metric, inch, diametrical pitch, module thread.The bed is made of high-grade cast iron The bed is undergoing surface quenching, the hardness can be HRC50.
Specifications | Unit | LFM6132A |
Max swing diameter over bed | mm | 330 |
Max swing diameter over table | mm | 185 |
Distance between centers | mm | 610 |
Taper of spindle bore |
| MT5 |
Spindle bore | mm | 40 |
Spindle speed/grade | rpm | 180~1930/8 |
Chuck specification |
| KZ11-160 |
Tool shank | mm | 20x20 |
Longitudinal travel | mm | 600 |
Cross travel | mm | 170 |
Small toolpost travel | mm | 85 |
Longitudinal feed/grade | mm | 0.1~0.4/3 |
Metric pitch/grade | mm | 0.5~3mm/10 |
Inch pitch/grade |
| 8~48.T.P.I/14 |
Tailstock taper |
| MT3 |
Power of main motor |
| One phsae, 220V/1.5kW 3 phase, 380V/1.5kW |
Net weight/ Gross weight | kg | 530/610 |
Overall dimensions of machine | mm | 1670x790x1480 |
