Large Spindle Bore Lathe- spindle hole 200mm

FOB Price

USD $10,500 - $30,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	Normal	Automatic Grade	Manual
Max. Swing Diameter	800mm	Place of Origin	Liaoning, China
Brand Name	Dalian	Model Number	LFM6163/6180, LFM6163/6180
After-sales Service Provided	Engineers available to service machinery overseas

Large Spindle Lathe sheet

Specifications	Unit	LFM6163	LFM6180
Max swing dia.over bed	mm	630	800
Max swing dia. over tool post	mm	345	550
Distance between two center	mm	750 1500 2000 3000 4000 6000 7000 8000	750 1500 2000 3000 4000 6000 7000 8000
Diameter range of pipe thread	mm		50~200
Width of bed	mm		490
Spindle bore	mm	Φ200	Φ200
Range of spindle speeds	rpm	14~750	36~480
Steps of spindle speed		18 steps	12 steps
Range/kinds of metric threads	mm	1~224mm/52kinds	1~14mm/24kinds
Range/kinds of inch threads		2~28T.P.I/40kinds	2~28T.P.I/40kinds
Range/kinds of module threads	mm	0.25~56mm/41kinds	0.25~56/41kinds
Range /kinds of diametrical pitch thread		1~112T.P.I/38kinds	1~112T.P.I/38kinds
Pitch of lead screw	mm	12.7	12.7
Max.longitudinal travel of saddle	mm		1310
Power of main motor	kW	11	11
Overall dimensions(LxWxH)	mm	5000x1449x1393	5157x1449x1393
Net weight	kg	5000	5500
