PLC Steel Roofing Roll Forming Machine PBR Panel Cold Roll Forming Equipment

PBR panel roll former

Descrition:

1) Main power:11KW made in China

2) Roll stations: 20 stations

3) 1.2\" inch chain drive

4) Diameter of shaft:￠85mm (3.35\")

5) Cutting system:hydraulic cutting

6) Length tolerance: 3m±1.0mm

7) Max working speed: 30m/min(100ft) (not including the cutting)

8) Thickness: 0.3mm--0.8mm , G550Mpa tensile painted steel.

9) Coil feeding width:1055-1092mm. (41.562\"--43\")

10) Material of roller:45# steel processment chromated ,HRC58-62

11) Material of blade mould:Cr12, quenched 58-62

12) 4 post hydraulic post cutting and 4 post hydraulic cutting

13) Hydraulic pressure :16Mpa

14) Hydraulic power:4kw

15) Size of machine: approx 10.3m*2.0m*1.8m

16) Chrome infeed guides

17) way of control:PLC Panasonic made in Japan

18) Electrical:440V,50Hz,3Ph or Accoring to the customer\'s demands

19) The safety guard is the steel nets with the yellow color

20) Machine structure:Torri stands (see the picture )

Applications:

PBR PANEL

PBR Roofing Panel

R panel

Profile Drawing

Flowchart

Competitive Advantage:

1. We have experienced engineer who engaged in designing the roll forming machines for 10 years

2. We have complete after-sales service system and we guanratee all life of the machines maintaince .

3. We can gurantee in-time delivery and well-done packaging
