PLC Control Roll Top Ridge Roll Forming Line With Hydraulic Shear
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Steel Seamed Pipe Forming Machine 0.6mm - 1.2mm PLC Tube Making Machine
-
5.5Kw Hydraulic Forming Machine 45# Forge Steel Roller For Facia Board
-
Colored Steel Sheet Octagonal Pipe Forming Machine , Sheet Metal Roll Former
-
Automatic Chain Drive Pipe Forming Machine 6 inch Half Round Forming Line
-
PLC Control Square Pipe Forming Machine 16 Roll Stations Single Chain Drive
-
5.5Kw Gutter Roll Forming Machine , Cold Roll Forming Equipment 380V 50Hz
Product Details
| Brand Name | HRF | Place of Origin | China | |
| Model Number | HRF462 |
Product Description
Certification:CE
462 Roll Top Ridge Forming Machine
Description:
We adopt the Torri stands structure to make the machine good looking and stands is chromed. Main machine motor power 5.5 motor made in china roller forming tation13 stations plus a set of film covering rolls Rolling speed is max 18m/min. Rolled material thickness is 0.3mm-0.8mm GI,PPGI,GL etc and coil width 462mm The rollers materials is 45# forge steel ,hard chromed,0.05mm .shafts material is 45#steel,diameter 70mm????? 4. We adopt hydraulic cutting ,hydraulic power3KW.cutting tolerance 1.5mm
Cutting pressure max 12Mpa ,cutting blade material:Cr12,quenched
????? 5. We adopt PLC control,Simense.Panasonic,Mitsubishi as options as well ,Yaskawa inverter speed control,Omron encoder measures the length .MSG touch screen made in Taiwan,size:152x68mm
????? 6. Size of machine: approx 6.5m*1.0m*1.4m and yellow safety cover and emergency stop is installed at the cutter and feeding point
Equipment:
5T manual decoiler, top side film covering unit,roll forming machine, hydraulic station, PLC cabinet, hydraulic shear,outables(2x2m)
Applications:
Ridge cap
Rolltop ridge
Specifications:
Drawing:
|
1 |
Material thickness |
mm |
0.3--0.8mm G350Mpa |
|
2 |
Forming speed |
m/min |
15-18m |
|
3 |
Roll station |
/ |
14 |
|
4 |
Main power |
kw |
5.5 |
|
5 |
Hydraulic power |
kw |
3 |
|
6 |
Control system |
/ |
PLC panasonic/omron/simens/mitsubishi |
|
7 |
Drive |
/ |
Chain drive |
|
8 |
Decoiler |
3T/manual decoiler ( coil car as option) |
