Full Auto 80 * 100 Sewer Pipe Roll Forming Machine With Manual Decoiler
- T/T L/C D/P D/A
- 7 days
You May Like
-
Hydraulic Aluminum Tube / Pipe Forming Machine 90 Max Bend Angle
-
45Kw Expressway Guardrail Roll Forming Machine Steel Wall Panel Roll Forming Equipment
-
Hydraulic Guardrail Roll Forming Machine PLC Control Cold Roll Forming Equipment
-
CNC Guardrail Beam Rolling Forming Machine 45 tims/min For Crash Barrier
-
2mm Guardrail Roll Forming Machine Auto Steel Sheet Roll Forming Line
-
Corrugated Guardrail Roll Forming Machine Vertical Wall Panel Curving Machine
Product Details
| Brand Name | HRF | Place of Origin | China | |
| Model Number | HRF80x100 |
Product Description
Certification:CE
?80x100 Downsprout Pipe forming machine
Description:
1) Main motor power:5.5Kw;
2) Forming speed:10-12m/min
3) Number of roller 19 stands
4) Rolled raw material: 0.3mm—1.0mm colored steel sheet or Alumnium sheet.
5) Shafts diameter:Ф70mm
6) Rollers manufacture:40Cr, hard Chrome Coated
5) Control system:Simens PLC made in Germany
6) Material of cutting die:Cr12 mold steel with quench treatment
7) Dimension of the machine: about7500mm×800mm×1200mm
8) Cutting pressure:12 Mpa
10 Cutting-length tolerance:≤±2mm
11) Control voltage:410 V,50Hz,3 Ph or 380V,50Hz,3Ph
?
Main Components of Manual Decoiler:
? Load capacity:1.5 Ton
? Coil inner-diametre:400-580mm
? Coil width:
Technological Process:
Decoiling → Coil sheet guiding&feeding → Roll forming → Cut to length → Product packing (manual)
Technical Parameter of Down Pipe Elbow:
? Control system: Strong electrical current
? Main motor power:2.2kw
? Max bend angle: 900
? Function: bend and fasten at the same time
? Dimension of the machine: 1300 mm×650 mm×1500 mm
? Speed of bend: 20-25m/ min
?
Work Flow:
?
Applications:
Downsprout pipe
Rainwater pipe
Downpipe
Specifications:
Drawing:
|
1 |
Material thickness |
mm |
0.3--1.0mm G350Mpa |
|
2 |
Forming speed |
m/min |
12-18 |
|
3 |
Roll station |
/ |
19 |
|
4 |
Main power |
kw |
5.5 |
|
5 |
Hydraulic power |
kw |
3 |
|
6 |
Control system |
/ |
PLC panasonic/omron/simens/mitsubishi |
|
7 |
Drive |
/ |
Chain drive |
|
8 |
Decoiler |
5T/ manual decoiler ( coil car as option) |
