Home > Products > Guardrail Roll Forming Machine > 45Kw Expressway Guardrail Roll Forming Machine Steel Wall Panel Roll Forming Equipment
45Kw Expressway Guardrail Roll Forming Machine Steel Wall Panel Roll Forming Equipment
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Hydraulic Guardrail Roll Forming Machine PLC Control Cold Roll Forming Equipment
-
CNC Guardrail Beam Rolling Forming Machine 45 tims/min For Crash Barrier
-
2mm Guardrail Roll Forming Machine Auto Steel Sheet Roll Forming Line
-
Corrugated Guardrail Roll Forming Machine Vertical Wall Panel Curving Machine
-
2.0mm - 3.5mm Highway Guardrail Curving Machine Joint Coupling Drive
-
Automatic Guardrail Roll Forming Machine Cold Roll Steel Panel Forming Machine
Product Details
| Brand Name | HRF | Place of Origin | China | |
| Model Number | HRF194 |
Product Description
Certification:CE
M194 Guardrail Forming Machine Line
Description:
The components of the whole line is 5T hydraulic decoiler, roll forming Machine ?including 2 rolls feeding, 7 rolls leveling as well 3 sets of holes punching units ,PLC cabinet, Hydraulic station, hydraulic cutting unit,2 simple runout tables We adopt Panasonic PLC control,Omron encoder measuring the length,Yaskawa speed variator made in Japan. It is easy and convient to operate the machine with stable performance and low noiseApplications:
Expressway guardrail
Barrier rails
Guardrail beams
Specifications:
The profile
The profile
Holes size punching:
1. main motor power: 45kw
2. Decelerating motor: BWD14-43-37kw, made in Shanghai or
Changzhou
3. drive: joint coupling drive( gearbox for each roller station see picture below)
4. main shaft dia: ￠100mm?? material: 45﹟forge steel
5. roller material: GCR15 quenched 58°-62°,chromed
6. roll station:13 stations
7. Working speed:5m--12m/min(not including punching)
8. Transducer: Panasonic /Yaskawa made in Japan. 380V 50HZ
9. Way of control: PLC,Panasonic
10. Computer operating panel:MSG touching screen made in Taiwan
Competitive Advantage:
Good quality and reasonable price
Contact Us
- Wuxi Hai Roll Fone Science&Tecnology Co.,Ltd
- Contact nameMr. zhao Chat Now
- Phone86-0510-81153870
- Address2-627,Xiangjiang North Road,New District,Wuxi City, Yan'an, Shaanxi
