PLC Control Square Pipe Forming Machine 16 Roll Stations Single Chain Drive
- T/T L/C D/P D/A
- 7 days
You May Like
-
5.5Kw Gutter Roll Forming Machine , Cold Roll Forming Equipment 380V 50Hz
-
Automatic Pipe Roll Forming Machine 0.3mm - 0.8mm Colored Steel Sheet
-
Full Auto 80 * 100 Sewer Pipe Roll Forming Machine With Manual Decoiler
-
Hydraulic Aluminum Tube / Pipe Forming Machine 90 Max Bend Angle
-
45Kw Expressway Guardrail Roll Forming Machine Steel Wall Panel Roll Forming Equipment
-
Hydraulic Guardrail Roll Forming Machine PLC Control Cold Roll Forming Equipment
Product Details
| Brand Name | HRF | Place of Origin | China | |
| Model Number | HRF3x4 |
Product Description
Certification:CE
3x4 Square Pipe Roll forming machine
Description:
Technology parameter:
1)Main power: 7.5KW
2)Roll station:16 stations
3)Size of roll forming machine:8.5m*1.0m*1.5m
4)Diameter of shaft:￠70mm
5)Thickness of formed :0.5-0.8mm,
6)Material of the roller: 45#forge steel , machined with numerical control, polished and coated with chrome
7)Length tolerance: 101.5mm
8)Working speed:12--15 m/min
9)1.0 inch single chain drive
10)Machine structure: Torii structure (standing tower system with chrome see the picture)
11)Electrical: According to your demands.
Applications:
Square pipe
Specifications:
Profile Drawing:
|
NO. |
Items |
Unit |
Main specification |
|
1 |
Material thickness |
mm |
0.4-0.9mm |
|
2 |
Forming speed |
m/min |
12-15 |
|
3 |
Roll station |
/ |
19 stations(depend on the profile) |
|
4 |
Main power |
kw |
5.5 |
|
5 |
Hydraulic power |
kw |
4 |
|
6 |
Control system |
/ |
PLC panasonic / Simens |
|
7 |
Drive |
/ |
by chain |
Flowchart
