Home > Products > Pipe Forming Machine > 5.5Kw Hydraulic Forming Machine 45# Forge Steel Roller For Facia Board
5.5Kw Hydraulic Forming Machine 45# Forge Steel Roller For Facia Board
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Colored Steel Sheet Octagonal Pipe Forming Machine , Sheet Metal Roll Former
-
Automatic Chain Drive Pipe Forming Machine 6 inch Half Round Forming Line
-
PLC Control Square Pipe Forming Machine 16 Roll Stations Single Chain Drive
-
5.5Kw Gutter Roll Forming Machine , Cold Roll Forming Equipment 380V 50Hz
-
Automatic Pipe Roll Forming Machine 0.3mm - 0.8mm Colored Steel Sheet
-
Full Auto 80 * 100 Sewer Pipe Roll Forming Machine With Manual Decoiler
Product Details
| Brand Name | HRF | Place of Origin | China | |
| Model Number | HRF35-280 |
Product Description
Certification:CE
35-280 Facia board roll forming machine
Description:
Main power:5.5 motor made in china Roller station:12 stations Size of machine: approx 6.0m*1.0m*1.4m Rolling speed:12--18m/min(not including the cutting) Shaft dia.:φ60mm Hydraulic power:3KW Working pressure:12Mpa Cutting blade material:Cr12,quenched 58-62 Sheet thickness:0.4-0.8mm Coil feed width:395mm material of roller: 45#forge steel No abrading on the surface Computer: PLC,Omron The computer is LCD touch-screenEquipment:
3T manual decoiler,roll forming machine, hydraulic station, PLC cabinet, hydraulic shear,outables(2x2m)
Applications:
Facia board
Facia panel
Specifications:
Drawing:
Flow chart:
Decoiler-feeding---forming--cutting-product-outables
Wuxi Hai Roll Fone Science & Technology Co.,Ltd is a professional manufacturer and supplier of roll forming equipment machine, slitting line, cut to length line machine and related metal sheet processing equipment in China. The products cover slitting machine, cutting machine, forming machine, MIC240/120 super K-span machine, wall/roof Panel forming machine, pipe welding machine, PU sandwich panel line and other related machines, including Hemming machine, W valley machine, Cranking machine, and Ridge cap machine and so on. Those roll forming equipments are used for all sorts of sheet metal forming and the vertical and horizontal shear. The products are mainly used in the construction industry, automobile manufacturing, machine manufacturing, electronics industry and many other areas.
