Steel Seamed Pipe Forming Machine 0.6mm - 1.2mm PLC Tube Making Machine
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
5.5Kw Hydraulic Forming Machine 45# Forge Steel Roller For Facia Board
-
Colored Steel Sheet Octagonal Pipe Forming Machine , Sheet Metal Roll Former
-
Automatic Chain Drive Pipe Forming Machine 6 inch Half Round Forming Line
-
PLC Control Square Pipe Forming Machine 16 Roll Stations Single Chain Drive
-
5.5Kw Gutter Roll Forming Machine , Cold Roll Forming Equipment 380V 50Hz
-
Automatic Pipe Roll Forming Machine 0.3mm - 0.8mm Colored Steel Sheet
Product Details
| Brand Name | HRF | Place of Origin | China | |
| Model Number | HRF88 |
Product Description
Certification:CE
88 Seamed Type Round Tube forming machine
?
Descrition:
Technical Parameter:
1)Suitable raw material: 0.6---1.2mm colored steel sheet or
galvanized steel(G300Mpa)
2. Main motor power:7.5Kw
3)Forming speed:10-12m/min
4)Number of roller stations: 20 and series of vertical rollers
5)Control system: PLC,Panasonic made in Japan
6)way of cutting: flying? saw cutting
7)Dimension of the machine: about8000mm×800mm×1200mm
10:Cut-to-length tolerance:≤±1.5mm
11)Control voltage: 380 V,50Hz,3 Ph or according to local standard
12)Shafts diameter:Ф68mm
13)Rollers manufacture:45#steel, machine tooling on the surface and polished
14)Omron encoder measures the length
15)Panasonic inverter made in Japan
16) mobile trailor is available
?Technical Parameter of Down Pipe Elbow:
?Control system: Strong electrical current
? Main motor power:2.2kw
?Max bend angle: 900
?Dimension of the machine: 1300 mm×650 mm×1500 mm
?Speed of bend: 20-25m/ min
?
Technological Process:
Work Flow:
?
manual decoiler--feeding&leveling----sheet forming--hydraulic cutting? after forming--outable
Applications:
Specifications:
Drawing:
|
1 |
Material thickness |
mm |
0.5-1.2mm G350Mpa |
|
2 |
Forming speed |
m/min |
12-15 |
|
3 |
Roll station |
/ |
20 |
|
4 |
Main power |
kw |
7.5 |
|
5 |
Saw cutting ?power |
kw |
3 |
|
6 |
Control system |
/ |
PLC panasonic/omron/simens/mitsubishi |
|
7 |
Drive |
/ |
Chain drive |
|
8 |
Decoiler |
5T/manual decoiler ( coil car as option) |
