Home > Products > Front Service LED Display > Front Opening P16 Front Service LED Display Advertising , 256mm * 256mm

Front Opening P16 Front Service LED Display Advertising , 256mm * 256mm

FOB Price

USD $ $1 - $ $1 / Set

1 Set(Min.Order)

Supply Ability 0 Set / Sets per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Newstar-LED		Place of Origin	China
Model Number	NS-OR-DD-P16

Product Description

Delivery Time:8-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

Quick Detail:

1.Perfect?vivid?image for sign or advertising

2.Long?lifespan?and?stable?work,?waterproof,?

3.LED?Display?Cabinet?design?for?easy?install?and?dismantle.?

4.Best?quality,?best?price.

5.?High viewing angle: 110°(Horizontal )/45°(Vertical )

6.?Brightness(cd/m2)≥ 8000

Front?Opening?P16?Front?Service?LED?Display?Advertising?,?256mm?*?256mm

Description:

1. Special Structure design for water-proof, dust-proof, moisture-proof, and anti-static electric

2. High viewing angle: 110°(Horizontal )/45°(Vertical )

3. High Contrast.?The Contrast is above 2000:1, so the viewer can have a wonderful visual

4. Outstanding consistency in color and brightness, no mosaic effects.

Applications:

Commercial advertising:?Square,?Road side, High way, Airport, Wharf, Hotel, Restaurant etc

Specifications:

1. Outdoor LED Display Technical Parameter

Model ?No.	NS-OR-DD-P16
Pixel Pitch?	16mm
Module Size	256mm×256mm
Module Resolution(dots)	16*16
Panel Size	1024mm×768mm
Panel Resolution(dots)	64×48
Pixel Configuration(RGB)	1R1G1B
Pixel Density(dots/m2)	3906
Brightness(cd/m2)	≥ 8000
Best Viewing Distance(m)	15-300
Max. Power Consumption(W/m2)	1000
Drive? Mode	Static
Wavelength	R? 620-625? G 520-525 B 470-475
Viewing??? Angle	110°(H)/45°(V)?
Operating?? Temperature	–20~60°C?
Video Frame Rate(Hz)	≥60HZ
Display? Refresh Rate(Hz)	≥300HZ
Grey? Level(colors)	16.7million
Lifespan	≥100,000 hours
Working Voltage	220V±15% OR 110V±15%
Video Signal Input	RF,S-Video, RGB,RGBHV,YUV,YC,COMPOSITION
Control System	LINSN OR? DB-STAR

2. Outdoor LED Display Module? ? ? ? ? ??

Module Size (W*H)	256mm*256mm	Pixel Configuration	1R1G1B
Pixel Pitch	16mm	? ? ?Resolution (W*H)	16 dots*16 dots
Pixel Density	3906 dots/㎡	LED Type	3mm Oval Lamp

3. Outdoor LED Display Cabinet

Cabinet Size (W*H)	1024mm*768mm	Module Qty	12 pcs
? Cabinet Resolution (W*H)	96 dots*64 dots	Cabinet Pixel	6144
Weight
