P20 1R1G1B Billboard LED Display For Advertising , Aluminum / Iron

Item

NS-OR-SD-P20

Physical Pitch

20mm

Physical Densi(pixels/m2)
(pixels/m2)

5000

LED Arrangement

1R1G1B

Module Resolution

16×8dots

Module Size(mm)

320×160mm

Cabinet Resolution

96×48dots

Cabinet Size(mm)

1280×960mm

Module Quantity

24pcs

Cabinet Weight

70KG

Brightness(cd/m2)

≥5000cd/m2

Contrast

≥2000:1

View Angle

110°/50°

Minimum View Distance

10m

Maxim Power Consumption (W/m2)

1000

Ave. Power Consumption (W/m2)

350

Operating Power Source

AC90-260V 50-60HZ

Grey Scale

10bits/1024levels

Color Capacity

1.07billion

Drive Mode

Constant Current,Dynamic 1/4Duty

Frame Frequency

60-85HZ

Refresh Rate

240-1000 HZ

Brightness Adjustment

0-100 8 levels automatic

Gamma Correction

-0.5---5.0

Correction Scale level

16 bits

Color Temperature

5000-9300K

Brightness Correction

Pixel,Module,Cabinet Correction

Protection Ratings

IP65(Front Side ),IP54(Back Side)

Control Distance

UTP CAT5E:100m;Multi-mode Fiber:500m; Single-mode Fiber:10KM

Out of Control Rate

0.01%

MTBF

5000 hours
