Home > Products > Stage Background LED Screen > Stage Background Led Screen P4 Led Curtain Display, Ultra Clear Indoor Led Screen For Concert

Stage Background Led Screen P4 Led Curtain Display, Ultra Clear Indoor Led Screen For Concert

FOB Price

USD $ $9 - $ $9 / Piece

1 Piece(Min.Order)

Supply Ability 0 Piece / Pieces per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Newstar-LED		Place of Origin	China
Model Number	LS-4

Product Description

Delivery Time:8-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

Stage background P4?LED Curtain Display, Ultra clear?Indoor led screen for concert

Quick Detail:

1. Unequalled brightness & extreme viewing angles

2. Slim, light-weight, modular design

3. Flexible shape and design

4. Accurate color uniformity and smoother, flicker-free video

5. Ultimate picture quality, longevity and low cost of ownership

6.??Waterproof Level: ?IP31?

Description:

1. Combining several global leading display board control technologies, such as grey?level code

technology, brightness control technology, and nonlinearly rectifying?technology

2. Modularization, high resolution and high contrast design, vivid dynamic display

3. Arbitrarily exchanging the display or displaying synchronized video

4. Long lifespan, can reach more than 100,000 hours, while the power consumption?is lower than one tenth

of lamp or neon

5. Economical maintenance and cost saving

Applications:

Commercial advertising, mobile media, night club, entertainment events, business establishments, such as

banks, stock exchange centers, bus station,schools,telecommunications,customs,stadiums,studio,shopping

malls, railways, airports, harbors, etc;

?

Specifications:

1. Indoor LED Display Technical Parameter

Model No.	LS-4
Pixel Pitch	4mm
Module Size	288*288mm
Module Resolution(pixels)	72*72
Panel Size	576mm×576mm
Panel Resolution(pixels)	144 × 144
Pixel Configuration(RGB)	1R1G1B
Pixel Density(pixels/m2)	62,500
Brightness(cdm2)	>1,500
Best Viewing Distance(m)	4-100
Max.Power Consumption(W/m2)	900
Waterproof Level	IP31
Wavelength	R 620-625 G 520-525 B 470-475
LED SPEC	2020
Viewing Angle	140°(H)/140°(V)
Operating Temperature	–40~60°C
Video Frame Rate(Hz)	≥60HZ
Display Refresh Rate(Hz)	≥300HZ
Grey Level(colors)	16.7million
MTBF	≥50,000 hours
Lifespan	≥100,000Hours
Working Voltage	220V±15% OR 110V±15%
Drive Mode	Constant 1/18
Graphics Card	DVI Graphics card
Video Signal	RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System	LINSN
Software	LED studio 10.0
Installation	Wall mount, hung and stand structure

2. Indoor LED Display Module

Dimensions (w x h)	288mm x 288mm	Resolution (w x h)	72 x 72
Pixel pitch	4mm	Pixel Density	62,500/㎡
Pixel Configration	1R1G1B 3 IN 1	LED Type	SMD 2020

3. Indoor LED Displ
