Home > Products > Billboard LED Display > CE Waterproof P10 SMD Billboard LED Display For Wedding , Conference
CE Waterproof P10 SMD Billboard LED Display For Wedding , Conference
- T/T L/C D/P D/A
- 7 days
You May Like
-
SMD Flexible Indoor LED Display Screen Signs P6 For Concerts , Trade Show 1R1G1B
-
1R1G1B P4 Indoor Full Color LED Display Signs Rental For Stage , Event 2000 cd/m2
-
DIP P20 Outdoor LED Display Board , 1R1G1B Sports Perimeter LED Display For Basketball Pitch
-
P16 Outdoor Sport Stadium LED Display Panel , 16*16 1R1G1B High Brightness LED Display
-
Full Color Advertising Football Stadium Perimeter LED Display Boards P12mm , 5800cd/
-
P10 Indoor Full Color LED Display , SMD 3528 Stage LED Screen Panel 1500 cd/m2
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | NS-OR-DS-P10 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. 24 months warranty. And lifelong free tech-support
2. CE and RoHS approval
3. Front accessible maintenance
4. Excellent contrast ratio, high definition
5. High brightness and perfect uniformity
6. Waterproof IP65
7. Available models: P8, P10, P12, P16, P20 ect.
CE?Waterproof?P10?SMD?Billboard?LED?Display?For?Wedding?,?Conference
Description:
1. High Contrast ratio: 4000:1
This is a very high level to ensure a vivid image of our LED display ?system.
2. First-class LED chip:
Supplied by high strictly selected SMD3535 LED
3. Clear vivid image quality:
Perfect color blending and comfortable visual effect
4. Easy Installation & Operation:
Slim and light LED panel, user friendly software for an easy interface to operate the LED system?
5. Easy maintenance:
Front and rear cabinet access maintenance
Applications:
Ideal for dazzling different events, such as Stage, Concert, Fashion Show, Wedding, Conference, Building,?
Hotel, Club & Bars, Festival, etc.
Specifications:
1. SMD Outdoor LED Display Technical Parameter
|
Model No. |
NS-IR-DS-P10 |
|
Pixel Pitch |
10mm |
|
Module Size |
320mm×160 mm |
|
Module Resolution(Pixel) |
32dots×16dots |
|
Pixel Density |
10000dots/m2 |
|
LED Type |
SMD 3 in 1 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/4 Duty Constant Current |
|
Cabinet Size |
960×960×135mm |
|
Cabinet Resolution |
96dots×96dots |
|
Brightness |
≥6000 cd/m2 |
|
Contrast |
≥ 2000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
10m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1000W/m2 |
|
Average Power Consumption |
350W/m2 |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85 HZ |
|
Refresh Frequency |
240 - 1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
Static:-40°C ~+85°C Working:-20~+65°C |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50,000 hours |
|
Computer Operation System |
Win 98/ Win XP/ Win 2000 |
|
Video Signal Input |
RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI, |
