Home > Products > Die-Casting LED Display > High Resolution P7.2 Outdoor Advertising LED Display For Banks

High Resolution P7.2 Outdoor Advertising LED Display For Banks

FOB Price

US$ $1 - $1 / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Newstar-LED		Place of Origin	China
Model Number	LS-7.2

Product Description

Delivery Time:8-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

Quick Detail:

1. Seamless assembly- Min 0.1mm cabinets gap.

2. With video processor control.

3. Brightness up to 7000 nits/sqm.

4.?Easy to Install and Maintain?

5.?Waterproof Level: IP41

6.?The rear cover\'s color can be customized

High?Resolution?P7.2?Outdoor?Advertising?LED?Display?For?Banks

Description:

1. Quick Lock Design

Can be fast installed and dismantled for large LED display— labor cost saved

2. No Fan No Noise:

Nature cool system design makes the LED display be more environmental and energy saves

3. Multi Color Options

The rear cover\'s color can be customized; you can choose the perfect color close to your logo.

Applications:

Commercial advertising, mobile media, night club, entertainment events, business establishments, such as

banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,

shopping malls, railways, airports, harbors, etc;

Specifications:

1. Outdoor LED Display Technical Parameter

Model No.	LS7.2
Pixel Pitch	7.2mm
Module Size	288*288mm
Module Resolution(pixels)	40*40
Panel Size	576mm×576mm
Panel Resolution(pixels)	144×144
Pixel Configuration(RGB)	1R1G1B
Pixel Density(pixels/m2)	62500
Brightness(cdm2)	7000
Best Viewing Distance(m)	4-100
Max.Power Consumption(W/m2)	1350
Waterproof Level	IP41
Wavelength	R 620-625 G 520-525 B 470-475
LED SPEC	2020
Viewing Angle	140°(H)/60°(V)
Operating Temperature	–20~50°C
Video Frame Rate(Hz)	≥60HZ
Display Refresh Rate(Hz)	≥300HZ
Grey Level(colors)	16.7million
MTBF	≥50000 hours
Lifespan	≥100000Hours
Working Voltage	220V±15% OR 110V±15%
Drive Mode	Constant 1/12
Graphics Card	DVI Graphics card
Video Signal	RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System	LINSN
Software	LED studio 10.0
Installation	Wall mount, hung and stand structure

2. Indoor LED Display Module

Dimensions (w x h)	288mmx288mm	Resolution (w x h)	40 x 40
Pixel pitch	7.2mm	Pixel Density	25600/㎡
