P10 Lightweight Outdoor Transparent LED Screen Curtain For Events
- T/T L/C D/P D/A
- 7 days
You May Like
-
P12 Outdoor Transparent LED Screen , SMD 3535 Curtain LED Display
-
Outdoor P15mm Transparent LED Screen Rental For Stage , High Brightness
-
P10mm RGB Front Service LED Display , Epistar / Silan Digital Display Board
-
Front Opening P16 Front Service LED Display Advertising , 256mm * 256mm
-
SMD3535 P6 Front Service LED Display Sign For Storefront
-
Double Sides P12 Outdoor LED Display Screen With Front Service
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | WS10 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Lightweight :< 8.5KG/panel. Ultra thin: 95mm thickness
2. Waterproof Level: IP65(Front Side), IP54 (Back Side)
3. High brightness: >6000cd/㎡
4. CE,CCC,RoHS,UL,ISO9001
5.?Made by high quality aluminum material
6.?Cabinet connection angle can be adjusted by -15 degree to +15 degree
P10?Lightweight?Outdoor?Transparent?LED?Screen?Curtain?For?Events
Description:
1. Light Weigh & Ultra Thin
Made by high quality aluminum material, one cabinet only weights 8.5 KG. It makes installation job and
delivery more comfortable and convenient. 95 mm thickness saves not only space for delivery but also
installation.
2. High brightness & Waterproof?
Brightness reaches 6000nits, IP65. It is perfect to be used for both indoor and outdoor.
3. Angle Adjustment?
Cabinet connection angle can be adjusted by -15 degree to +15 degree.?This allows you shape arc
shapes.
4. Fast Lock System & No Fan Design
Easy to install and dismantle: an average worker can finish 70 panels per hour. Natural cool system design
and good heat dissipation.
Applications:
Events, Rental, Show, Exhibition, Stage, Entertainment, Concerts
Specifications:
1. WS10 Technical Parameter? ?
|
Model No. |
WS10 |
|
Pixel Pitch |
10.417mm |
|
Module Size |
500mm*83.33mm |
|
Module Resolution (W*H) |
48 dots*8 dots |
|
Pixel Density |
9216 dots/ ㎡ |
|
LED Type |
SMD 3535 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/4 Duty Constant Current |
|
Cabinet Size |
500×500×95mm |
|
Cabinet Resolution |
48dots×48dots |
|
Brightness |
≥6000cd/㎡ |
|
Contrast |
≥2000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
7m-300m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1500 W/m2 |
|
Average Power Consumption |
700 W/m2 |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85 HZ |
|
Refresh Frequency |
240 - 1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
-40~+65℃ |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50,000 hours |
|
Computer Operation System |
Win 98/ Win XP/ Win 2000 |
|
|
