P6.25mm Aluminum Alloy Indoor Full Color LED Display Screen 1R1G1B , Light Weight
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
P6 High Resolution Indoor Full Color Led Display for Shopping Malls 1R1G1B 2000 cd/m2
-
P7.62mm Indoor Full Color LED Screen for Stage , High Brightness 140(H)/60(V)
-
P8 Rental LED Video Wall , SMD Indoor LED Full Color Display For Bus Station
-
1R1G1B P15mm Stage Background LED Screen Rental , Outdoor Lightweight
-
High Resolution curtain P10.417 Transparent LED Screen , Outdoor Aluminum LED display
-
1R1G1B SMD 3 In 1 P7.62 Stage Background LED Screen Rental For Show Advertising
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | CS-6 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Excellent contrast ratio, high resolution/high definition
2. Perect uniformity and no mosaic
3. Light weight 8kg per panel
4. Available models: P3.91, P4.46,P5.2, P6.25.
5. Aluminum materil, heat dissipation fast.
6. Long lifespan up to 100,000 hours.
P6.25mm Aluminum Alloy Indoor Full Color LED Display Screen 1R1G1B , Light Weight
Description:
1. Ultra slim cabinet
Each panel is only 500*500mm, thickness is 55mm, weights 8Kg.
2. Clear vivid image quality:
High refresh rate 1000Hz, without any loss of grey level.
3. Easy Installation & Operation:
Full aluminum design with exquisite design, user friendly software for an easier operation
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,
shopping malls, railways, airports, harbors, etc;
Specifications:
1. Indoor LED Display Technical Parameter? ??
|
Model No. |
NS-IR-DS-P6.25 |
|
Pixel Pitch |
6.25mm |
|
Module Size |
250*250mm |
|
Module Resolution(pixels) |
32*32 |
|
Panel Size |
500mm×500mm |
|
Panel Resolution(pixels) |
80×80 |
|
Pixel Configuration(RGB) |
1R1G1B |
|
Pixel Density(pixels/m2) |
25600 |
|
Brightness(cdm2) |
2000 |
|
Best Viewing Distance(m) |
6-100 |
|
Max.Power Consumption(W/m2) |
1350 |
|
Waterproof Level |
IP21 |
|
Vavelength |
R 620-625 G 520-525 B 470-475 |
|
LED SPEC |
3528 |
|
Viewing Angle |
140°(H)/60°(V) |
|
Operating Tempreture |
–20~50°C |
|
Video Frame Rate(Hz) |
≥60HZ |
|
Display Refresh Rate(Hz) |
≥300HZ |
|
Grey Level(colors) |
16.7million |
|
MTBF |
≥50000 hours |
|
Lifespan |
≥100000Hours |
|
Working Voltage |
220V±15% OR 110V±15% |
|
Drive Mode |
Constant 1/10 |
|
Graphics Card |
DVI Graphics card |
|
Video Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
|
Control System |
LINSN |
|
Software |
LED studio 10.0 |
|
Installation |
Wall mount, hung and stand structure |
2. Indoor LED Display Module? ? ? ?
|
Dimensions (w x h) |
250mmx250mm |
Resolution (w x h) |
40 x 40 |
|
Pixel pitch |
6.25mm |
Pixel Density |
25600/㎡ |
|
Pixel Configration |
1R1G1B 3 IN 1 |
SMD3528 |
3. Indoor LED Display Cabinet?
|
Dimensions(w x h x d)(mm) |
500x500x75 |
Module Quantity |
4 |
|
Physical Resolution (w x h) |
