P20 Wall Mounted Front Service LED Display Outdoor For Advertising

FOB Price

US$ $600 - $600 / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Newstar-LED		Place of Origin	China
Model Number	NS-OR-DD-P20

Product Description

Delivery Time:20-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

Quick Detail:

1.Brightness≥5000

2. Wide viewing angle and large viewing distance video LED

3. Front service

4. Energy saving

5. CE.RoHS,CCC,ISO,UL

6.?Long?Lifespan > 100,000 hours

P20?Wall?Mounted?Front?Service?LED?Display?Outdoor?For?Advertising

Description:

1. Durable fresh color and High brightness

65536 ?grey scale and the 281 billion color and more than 1200 HZ refresh rate ensure wonderful video

color presentation?

2. Energy Saving?

Adopt high-brightness LED with low consumption and 90% ?efficiency ?power supply saving 20% power

energy.?

3. Stability and reliability

Precise manufacturing process keeps the modules rugged and durable.?

Applications:

Outdoor full color?digital?billboards are very popular in LED display advertising field.?These type digital?

billboards are widely used ?in outdoor plaza, outdoor building, stadium, shopping mall, cross road ,highway,

airport etc;

Specifications:

1. Outdoor LED Display Technical Parameter

Item	NS-OR-SD-P20
Physical Pitch	20mm
Physical Densi(pixels/m2) (pixels/m2)	5000
LED Arrangement	1R1G1B
Module Resolution	16×8
Module Size(mm)	320×160
Cabinet Resolution	96×48
Cabinet Size(mm)	1280×960
Module Quantity	24pcs
Cabinet Weight	70KG
Brightness(cd/m2)	≥5000
Contrast	≥2000:1
View Angle	110°/50°
Minimum View Distance	10m
Maxim Power Consumption (W/m2)	1000
Ave. Power Consumption (W/m2)	350
Operating Power Source	AC90-260V 50-60HZ
Grey Scale	10bits/1024levels
Color Capacity	1.07billion
Drive Mode	Constant Current,Dynamic 1/4Duty
Frame Frequency	60-85HZ
Refresh Rate	240-1000 HZ
Brightness Adjustment	0-100 8 levels automatic
Gamma Correction	-0.5---5.0
Correction Scale level	16 bits
Color Temperature	5000-9300K
Brightness Correction	Pixel,Module,Cabinet Correction
Protection Ratings	IP65(Front Side ),IP54(Back Side)
Control Distance	UTP CAT5E:100m;Multi-mode Fiber:500m; Single-mode Fiber:10KM
Out of Control Rate	0.01%
MTBF	5000hrs
Operating life Span
