　　Detailed description

　　Mobile machines,including all kinds of mobile intelligent robots and AGV vehicles,the power of its own source is the battery.In order to ensure that the mobile machinery can be continuous,stable,safe and reliable work,reasonable configuration of power supply,choose to use high efficiency,and low cost battery,it is very important.

　　STECO SAPHIR Power Group Limited is the world's most advanced power supply manufacturer.To meet the requirements of emerging applications,with its advanced manufacturing equipment and processes,the latest patented technology and materials,designed for mobile mechanical power supply adsorption(AGM)AX series maintenance-free lead-acid sealed batteries.The series of batteries in strict compliance with the international standard battery production,not only to strengthen the deep cycle discharge and fast charge capacity,but also improve the use of security and reliability,no damage to equipment and the environment,no pollution.

　　Follow the standard

　　●Product design in line with international standards IEC 60896/21-22

　　●In accordance with the Eurobat guidelines issued in 1999,this series of products belong to the"long life"category

　　●Complies with Telcordia SR-4228

　　●UL certification(UL standard 1989)

　　●According to the US"DOT Regulation 49"and the ICAO ICAO and IATA"Packaging Directive 806",it was approved as a non-dangerous goods suitable for land,sea and air transport

　　●certified by ISO 9001:2000 and ISO 14001:2004 certified STECO SAPHIR factory production

Specifications and technical specifications


　　Detailed description

　　STECO SAPHIR HuaDa AGV Safe series of lead-acid battery charger is a high-frequency switching power supply as the core,the main power converter using high-frequency high-permeability nanocrystalline transformers,microcomputer control of intelligent automatic charger.

　　High-tech applications,improve the efficiency of the whole conversion.Products with high efficiency,energy saving significant features,compared to traditional charger energy saving 20%-30%.

　　This series of microcomputer computer built-in a variety of battery charging program,accurate simulation of different types of battery charging curve.Choose a different charging program,can AGM,colloid,semi-colloidal and rich liquid water and other lead-acid batteries to charge.

　　The charging system consists of the charger and the charged battery to form a binary closed loop circuit.The dU/dt and dI/dt techniques are used to dynamically track the battery to accept the current.The microcomputer automatically determines the parameters of the on-line charging program according to the status of the battery,controls the output current and voltage Charging time,the charging current from the beginning to the end of the battery in the vicinity of the acceptable charge current curve,so that the battery almost no gas precipitation conditions.Not only save electricity,to achieve rapid charging,but also no damage to the battery to extend battery life.Current output is the pulse current mode,improve the battery charging capacity,reduce the concentration of polarization,electrochemical polarization,reduce gas generation.This is a very important way to reduce the battery temperature rise,reduce the battery plate deformation,reduce the gas flushing plate,reduce the active material off.

　　This series of charger with anti-battery reverse,the output short circuit,the output overload protection.Also has the function of automatic switch machine,can be connected to long-term input power.Need to charge,connect the battery pack,the charger work;no charge,disconnect the battery pack,the charger to stop working,the operation is very simple,user-friendly.

　　STECO SAPHIR HuaDa intelligent automatic lead-acid battery charger is a high reliability,high stability of the new energy-saving lead-acid battery charger.

　　Specifications Model

　　Product model

　　Charging mode

　　Charging voltage/current

　　Battery capacity

　　Outline size

　　Net weight

　　Input power

　　Cell voltage

　　Ah

　　W*H*L(mm)

　　Kg

　　TP4-24

　　Three stage constant current

　　24V/4A

　　20-40

　　195*150*340

　　7

　　1Ф220VAC

　　TP8-24

　　Three stage constant current

　　24V/8A

　　45-70

　　195*150*340

　　7

　　1Ф220VAC

　　TP15-24

　　Three stage constant current

　　24V/13A

　　60-100

　　195*150*340

　　7

　　1Ф220VAC

　　TP20-24

　　Three stage constant current

　　24V/20A

　　100-150

　　195*150*340

　　7

　　1Ф220VAC

　　TP25-24

　　Three stage constant current

　　24V/25A

　　150-210

　　195*150*340

　　7

　　1Ф220VAC

　　TP30-24

　　Three stage constant current

　　24V/30A

　　180-250

　　195*150*340

　　8

　　1Ф220VAC

　　TP35-24

　　Three stage constant current

　　24V/35A

　　240-320

　　200*160*360

　　9

　　1Ф220VAC

　　TP15-48

　　Three stage constant current

　　48V/13A

　　60-100

　　195*150*340

　　7

　　1Ф220VAC

　　TP20-48

　　Three stage constant current

　　48V/20A

　　100-150

　　195*150*340

　　8

　　1Ф220VAC

　　TP25-48

　　Three stage constant current

　　48V/25A

　　150-210

　　195*150*340

　　9

　　1Ф220VAC

　　TP30-48

　　Three stage constant current

　　48V/30A

　　180-250

　　200*160*360

　　9

　　1Ф220VAC

　　TP40-48

　　Three stage constant current

　　48V/40A

　　240-320

　　200*160*360

　　10

　　1Ф220VAC

　　TP50-48

　　Three stage constant current

　　48V/50A

　　360-420

　　265*180*420

　　15

　　1Ф220VAC

　　TP15-72

　　Three stage constant current

　　72V/13A

　　60-100

　　195*150*340

　　8

　　1Ф220VAC

　　TP20-72

　　Three stage constant current

　　72V/20A

　　100-150

　　195*150*340

　　9

　　1Ф220VAC

　　TP25-72

　　Three stage constant current

　　72V/25A

　　150-210

　　200*160*360

　　10

　　1Ф220VAC

　　TP30-72

　　Three stage constant current

　　72V/30A

　　180-250

　　200*160*360

　　12

　　1Ф220VAC

　　TP15-96

　　Three stage constant current

　　96V/13A

　　60-100

　　195*150*340

　　8

　　1Ф220VAC

　　TP20-96

　　Three stage constant current

　　96V/20A

　　100-150

　　200*160*360

　　10

　　1Ф220VAC

　　TP25-96

　　Three stage constant current

　　96V/25A

　　150-210

　　265*180*420

　　15

　　1Ф220VAC

　　Protection characteristics

　　Overheating protection:when the internal temperature of the charger is over 75 degrees,the charger can be shutdown and the temperature will drop automatically to recharge the battery.

　　?short-circuit protection:when the charger output unexpected short circuit,the charger automatically shut down the output,after troubleshooting,delayed 10 seconds,restart charging.

　　Overheating protection:when the internal temperature of the charger is over 75 degrees,the charger can be shutdown and the temperature will drop automatically to recharge the battery.

　　?short-circuit protection:when the charger output unexpected short circuit,the charger automatically shut down the output,after troubleshooting,delayed 10 seconds,restart charging.

　　Technical index

　　Rated input voltage:AC220V+15%

　　?rated frequency:45~65 Hz

　　Battery voltage:24V/48V/72V/96V and so on

　　The full load efficiency:93%

　　?maximum charging current:4,8,13,20,25A,etc.

　　The average charge and floating charge:automatically

　　Battery type:AGM,colloid,semi colloid and water rich water injection battery(charging program has been set at the factory.If you have to make a choice again,you need to do it under the guidance of a professional

　　Shutdown mode:automatic,or timer,or disconnect the charging plug,automatic shutdown

　　Cooling mode:forced air cooling

　　Display mode:LED digital meter,with LED light indication charging state

　　Mechanical shock and seismic rating:comply with SAEJ1378 requirements

　　Protection level:IP46

　　Operating temperature:-5 DEG C to+45 DEG C

　　Storage temperature:-30 DEG C to+70 DEG C

　　Charging control:temperature compensation control,never overcharge,lack of charge

　　Battery charging curve

　　Smart Charging Station

　　Indicator light display

　　Red light-charging in progress.

　　The yellow light-the lights,the battery into floating state.When the yellow light is on,the capacity of the battery has reached 90%.After 2 hours,it reaches more than 96%.After 5 hours,it reaches more than 99%.

　　Light green-charging program complete.Battery capacity is more than 100%.

　　Display

　　Check the button in the panel:A-U-charge current,battery voltage,H charging time,charging C ah,E power.Button to see the parameters,the display automatically restores the charging current after 5 seconds.
