P7.81 indoor Curtain LED Display , 16394dots/ led screen for rental stage
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
P5.21 SMD Slim Rental LED Display , Stage Background LED Screen
-
Lightweight Rental P15 Transparent LED Screen Curtain For Stage
-
Outdoor IP65 P12 Transparent LED Screen , Ultra Thin LED Display
-
P10 Lightweight Outdoor Transparent LED Screen Curtain For Events
-
P12 Outdoor Transparent LED Screen , SMD 3535 Curtain LED Display
-
Outdoor P15mm Transparent LED Screen Rental For Stage , High Brightness
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | WS-7 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
P7.81 indoor Curtain LED Display , 16394dots/㎡ led screen for rental stage
Quick Detail:
1. More than 1,500cd/㎡ brightness
2. Waterproof Level: IP65(Front), IP54 (rear)
3. Lightweight :< 8KG/panel.
4. CE,CCC,RoHS,UL,ISO9001
5. Ultra thin: 95mm thickness
6. Cabinet connection angle can be adjusted by -15° ~?+15 °.
Description:
1. High brightness & Waterproof
Brightness gets more than 15000nits, IP65. Newstar LED curtain provides a terrific solution for events and
rental business.
2. Lightweight & Pretty Thin
Made by high quality aluminum material, one cabinet only weights 8KG. It makes installation job and
delivery more comfortable and convenient. 95 mm thickness saves not only space for delivery but also
installation.
3. Angle Adjustment
Cabinet connection angle can be adjusted by -15 degree to +15 degree.?This allows you can shape arc
shapes.
4. Fast Lock System & No Fan Design
Easy to install and dismantle: an average worker can finish 70 panels per hour. Natural cool system design and good heat dissipation.
Applications:
Events, Rental, Show, Exhibition, Stage, Entertainment, Concerts.
Specifications:
1. WS7 Technical Parameter? ? ?
|
Model No. |
WS7 |
|
Pixel Pitch |
7.81mm |
|
Module Size |
500mm*62.5mm |
|
Module Resolution (W*H) |
64 dots*8 dots |
|
Pixel Density |
16,394 dots/ ㎡ |
|
LED Type |
SMD 3528 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/4 Duty Constant Current |
|
Cabinet Size |
500 ×500 ×95mm |
|
Cabinet Resolution |
64dots ×64dots |
|
Brightness |
≥1,500cd/㎡ |
|
Contrast |
≥ 4000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
7m-100m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16,777,216 |
|
Color Temperature |
5000-9300K |
|
Average Power Consumption |
100W/㎡ |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85 HZ |
|
Refresh Frequency |
240 - 1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
-40~+65℃ |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50,000 hours |
|
Computer Operation System |
Win 98/ Win XP/ Win 2000 |
|
Video Signal Input |
RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite |
|
Video Signal Output |
RF, S-Video, RGB, RGBHV, YUV, YC etc. |
|
Graphics Card |
DVI Graphics Card |
|
Control Distance |
LINSN / NOVA / DB-STAR |
|
Software |
LED studio 10.0 |
|
Waterproof Level |
