Double Sides P12 Outdoor LED Display Screen With Front Service
- T/T L/C D/P D/A
- 7 days
You May Like
-
P16 Rental Stage Background LED Screen Curtain , Outdoor Lightweight
-
High Resolution P6 Stage Background LED Display Full Color , SMD3528
-
P10 RGB SMD3535 Stage LED Display Curtain For Celebration Event
-
Advertising P16mm Truck Mounted LED Display Panel For Outdoor , High Contrast 8000cd/
-
IP65 SMD 3528 P8mm Billboard LED Display Outdoor For Shopping Mall
-
P10 Electronic Billboard LED Display Advertising , High Definition
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | NS-OR-DD-P12 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Front opening door
2. Save maintenance space
3. Fully waterproof IP65
3. Clear vivid image quality
4. Easy Installation & Using
5.?Brightness≥6000 cd/m2
6.?Long?Lifespan > 100,000 hours
Double?Sides?P12?Outdoor?LED?Display ?With?Front?Service
Description:
1. Front service of cabinet for easy maintenance
2. Different video frequency can be changed freely at the same time, and the image?can be enlarged and
reduced
3. Play different formats of image files, flash, WAV/MIDI, video signal from?TV, video signal from video and
other equipment
4. High brightness, and can be adjustable, meets the need of changing requirement?of customer in
environment
Applications:
Commercial advertising:?Square,?Road side, High way, Airport, Wharf, Hotel, Restaurant etc
Specifications:
1. Outdoor LED Display Technical Parameter
|
Model No. |
NS-OR-DD-P12 |
|
Pixel Pitch |
12mm |
|
Module Size |
192 mm ×192mm |
|
Module Resolution(Pixel) |
16 dots×16dots |
|
Pixel Density |
6944 dots/m2 |
|
LED Type |
3mm Oval Lamp |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/4 Duty Constant Current |
|
Cabinet Size |
1152×768×150mm |
|
Cabinet Resolution |
96dots×64dots |
|
Brightness |
≥6000 cd/m2 |
|
Contrast |
≥2000:1 |
|
Viewing Angle |
110°(Horizontal )/45°(Vertical ) |
|
Best Viewing Distance |
10~300 m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1000 W/m2 |
|
Average Power Consumption |
350W/m2 |
|
Working Voltage |
AC220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
≥60HZ |
|
Refresh Frequency |
≥240HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
Static:-40°C ~ +85°C Working:-20°C ~ +60°C |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50000 hours |
|
Computer Operation System |
Win 98/ Win XP/ Win 2000 |
|
Video Signal Input |
RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite |
|
Video Signal Output |
RF, S-Video, GB, RGBHV, YUV, YC etc. |
|
Graphics Card |
