Home > Products > Stage Background LED Screen > 1R1G1B SMD 3 In 1 P7.62 Stage Background LED Screen Indoor Rental For Show
1R1G1B SMD 3 In 1 P7.62 Stage Background LED Screen Indoor Rental For Show
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Brightness Truck Mounted LED Screen
-
Full Color Outdoor Advertising LED Display Billboard
-
P7.81 indoor Curtain LED Display , 16394dots/ led screen for rental stage
-
P5.21 SMD Slim Rental LED Display , Stage Background LED Screen
-
Lightweight Rental P15 Transparent LED Screen Curtain For Stage
-
Outdoor IP65 P12 Transparent LED Screen , Ultra Thin LED Display
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | NS-IR-DS-P7.62 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
R1G1B SMD 3 In 1 P7.62 LED Stage Display Indoor Rental for Show
Quick Detail:
1. Unequalled brightness & extreme viewing angles
2. Slim, light-weight, modular design
3. Flexible shape and design
4. Accurate color uniformity and smoother, flicker-free video
5. Ultimate picture quality, longevity and low cost of ownership
6.??Waterproof Level: ?IP31?
Description:
1. Combining several global leading display board control technologies, such as grey?level code
technology, brightness control technology, and nonlinearly rectifying?technology
2. Modularization, high resolution and high contrast design, vivid dynamic display
3. Arbitrarily exchanging the display or displaying synchronized video
4. Long lifespan, can reach more than 100,000 hours, while the power consumption?is lower than one tenth of lamp or neon
5. Economical maintenance and cost saving.
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station,schools,telecommunications,customs,stadiums,studio,shopping
malls, railways, airports, harbors, etc;
?
Specifications:
1. Indoor LED Display Technical Parameter
|
Model No. |
NS-IR-DS-P7.62 |
|
Pixel Pitch |
7.62mm |
|
Module Size |
244*122mm |
|
Module Resolution(pixels) |
32 *16 |
|
Panel Size |
976mm×732mm |
|
Panel Resolution(pixels) |
128 *96 |
|
Pixel Configuration(RGB) |
1R1G1B |
|
Pixel Density(pixels/㎡) |
17,222 |
|
Brightness(cd/㎡) |
1800 |
|
Best Viewing Distance(m) |
6-100 |
|
Max.Power Consumption(W/㎡) |
1000 |
|
Waterproof Level |
IP31 |
|
Wavelength |
R 620-625 G 520-525 B 470-475 |
|
LED SPEC |
3528 |
|
Viewing Angle |
140°(H)/140°(V) |
|
Operating Temperature |
–20~60°C |
|
Video Frame Rate(Hz) |
≥ 60HZ |
|
Display Refresh Rate(Hz) |
≥ 300HZ |
|
Grey Level(colors) |
16.7million |
|
MTBF |
≥50,000 hours |
|
Lifespan |
≥100,000Hours |
|
Working Voltage |
220V±15% OR 110V±15% |
|
Drive Mode |
Constant 1/8 |
|
Graphics Card |
DVI Graphics card |
|
Video Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
|
Control System |
LINSN |
|
Software |
LED studio 10.0 |
|
Installation |
Wall mount, hung and stand structure |
2. Indoor LED Display Module
|
Dimensions (w x h) |
244mmx122mm |
Resolution (w x h) |
32 x 16 |
|
Pixel pitch |
7.62mm |
Pixel Density |
17,222/㎡ |
|
Pixel Configration |
1R1G1B 3 IN 1 |
LE Type |
SMD 3528 |
3. Indoor LED Display Cabinet
