Wall Mounted P20mm Flexible LED Display Board , Full Color Led Signs
- T/T L/C D/P D/A
- 7 days
You May Like
-
Die Casting HD Indoor Rental LED Display P3.91 with Full Color , Constant 1/10
-
P16 Flexible LED Screen Soft LED Display Full Color For Night Club
-
P12 1R1G1B Flexible Led Display Outdoor For Crossroad Advertising
-
P6 SMD Video Flexible Led Display Indoor With High Resolution
-
High Brightness P12 Curved LED Display For Entertainment Events
-
P4 SMD2020 Indoor Front Service LED Display For Mobile Media
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | NS-OR-DD-P20 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. ≤1mm surface level up, smooth video
2. Long lifespan up to 100,000 hours
3. High brightness: >6000cd/㎡
4. IP65 Ruggedness, all-weather qualified
5. Support any format of video, RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION
6. Perfect quality and stability, 24/7 running
P20?Wall?Mounted?Flexible?LED?Display?Board?,?Full?Color?Led?Signs
Description:
1. Durable fresh color and High brightness
65536 ?grey scale and the 281 billion color and more than 1200 HZ refresh rate ensure wonderful video
color presentation?
2. Energy Saving?
Adopt high-brightness LED with low consumption and 90% ?efficiency ?power supply saving 20% power
energy.?
3. Stability and reliability
Precise manufacturing process keeps the modules rugged and durable.?
Applications:
outdoor full color?digital?billboard are very popular in LED display advertising field.?This type digital?
billboards are widely used??Outdoor plaza, Outdoor building, stadium, shopping mall, cross road ,highway,
airport etc;
Specifications:
1. Outdoor LED Display Technical Parameter
|
Item |
NS-OR-SD-P20 |
|
Physical Pitch |
20mm |
|
Physical Densi(pixels/m2) |
5000 |
|
LED Arrangement |
1R1G1B |
|
Module Resolution |
16×8 |
|
Module Size(mm) |
320×160 |
|
Cabinet Resolution |
96×48 |
|
Cabinet Size(mm) |
1280×960 |
|
Module Quantity |
24pcs |
|
Cabinet Weight |
70KG |
|
Brightness(cd/m2) |
≥5000 |
|
Contrast |
≥2000:1 |
|
View Angle |
110°/50° |
|
Minimum View Distance |
10m |
|
Maxim Power Consumption (W/m2) |
1000 |
|
Ave. Power Consumption (W/m2) |
350 |
|
Operating Power Source |
AC90-260V 50-60HZ |
|
Grey Scale |
10bits/1024levels |
|
Color Capacity |
1.07billion |
|
Drive Mode |
Constant Current,Dynamic 1/4Duty |
|
Frame Frequency |
60-85HZ |
|
Refresh Rate |
240-1000 HZ |
|
Brightness Adjustment |
0-100 8 levels automatic |
|
Gamma Correction |
-0.5---5.0 |
|
Correction Scale level |
16 bits |
|
Color Temperature |
5000-9300K |
|
Brightness Correction |
Pixel,Module,Cabinet Correction |
|
Protection Ratings |
IP65(Front Side ),IP54(Back Side) |
|
Control Distance |
UTP CAT5E:100m;Multi-mode Fiber:500m; Single-mode Fiber:10KM |
|
Out of Control Rate |
0.01% |
|
MTBF |
5000hrs |
|
Operating life Span |
100000hrs |
|
Operating Temperature |
-40°C~+65°C |
|
Operating Humidity |
10~90%RH |
2. Outdoor LED Display Module? ? ? ? ? ??
|
Module Size (W*H) |
320mm*160m |
