Lightweight Rental P15 Transparent LED Screen Curtain For Stage
- 0 Meter / Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Outdoor IP65 P12 Transparent LED Screen , Ultra Thin LED Display
-
P10 Lightweight Outdoor Transparent LED Screen Curtain For Events
-
P12 Outdoor Transparent LED Screen , SMD 3535 Curtain LED Display
-
Outdoor P15mm Transparent LED Screen Rental For Stage , High Brightness
-
P10mm RGB Front Service LED Display , Epistar / Silan Digital Display Board
-
Front Opening P16 Front Service LED Display Advertising , 256mm * 256mm
Product Details
Brand Name | Newstar-LED | Place of Origin | China | |
Model Number | WS15 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1.? Lightweight :< 8.5KG/panel. Ultra thin: 95mm thickness
2. High brightness: >7000cd/㎡
3. Waterproof Level: IP65(Front Side), IP54 (Back Side)
4. CE,CCC,RoHS,UL,ISO9001
5.?Made by excellent aluminum material
6.?Cabinet connection angle can be adjusted by -15 degree to +15 degree
?
Lightweight?Rental?P15?Transparent?LED?Screen?Curtain?For?Stage
Description:
1. Light Weight & Pretty Thin
Made by excellent aluminum material, each panel only weights 8.5 KG which makes installation job and
delivery be much more comfortable and convenient. Pretty thin, thickness 95m m not only saves delivery
space but also saves installation space.
2. High brightness & Waterproof
Brightness up to 7000nits, IP65 waterproof level. It provides a perfect solution for outdoor stage use.
3. Angle Adjustment
Cabinet connection angle can be adjusted by -15 degree to +15 degree.?This allows you ?shape arc
shapes.
4. Fast Lock System & Natural Cooling System Design
Fast lock system enables installation and dismantle to be much faster: an average worker can finish 50- 70
panels per hour. Natural cool system design results in good heat dissipation and less power consuming.
Applications:
Rental, Stage, Events, Show, Exhibition, Entertainment, Concerts
Specifications:
1. WS15 Technical Parameter? ? ?
Model No. |
WS15 |
Pixel Pitch |
15.625mm |
Module Size |
500mm*62.5mm |
Module Resolution (W*H) |
32 dots*4 dots |
Pixel Density |
4096 dots/ ㎡ |
LED Type |
SMD 3535 |
Pixel Configuration |
1R1G1B |
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
Drive Mode |
Dynamic 1/4 Duty Constant Current |
Cabinet Size |
500×500×95mm |
Cabinet Resolution |
32dots×32dots |
Brightness |
≥7000cd/㎡ |
Contrast |
≥4000:1 |
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
Best Viewing Distance |
7m-300m |
Grey Scale |
10bits/1024levels |
Color Capability |
16777216 |
Color Temperature |
5000-9300K |
Maximum Power Consumption |
1500 W/m2 |
Average Power Consumption |
700 W/m2 |
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
Frame Frequency |
60-85 HZ |
Refresh Frequency |
240 - 1000HZ |
Brightness Correction |
Pixel, Module, Cabinet Correction |
Operating Temperature |
-40~+65℃ |
Operating Humidity |
10-90% RH |
LED Lifespan |
100,000 hours |
MTBF |
≥50,000 hours |
Co |
