XL5032 Economic Universal Vertical Milling Machine with CE

FOB Price

USD $5,374 - $33,971 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Liaoning, China
Brand Name	LFM	Model Number	XL5032
Type	Universal	CNC or Not	Normal
Voltage	220V/380V/415V/440V/480V	Power(W)	5.5kW
Dimension(LWH)	2294x1770x1900mm	Weight	3000kgs
Certification	CE; ISO9001:2008; GB/T19001:2008	Warranty	12 months
After-sales Service Provided	Engineers available to service machinery overseas

XL5032 vertical milling machine technical data

Product Introduction

vertical milling machine has following features:

1. one more powerful metal cutting machine,

2. high rigidity,

3. wide range of spindle feed also can bear a heavy burden.

4. the spindle taper hole can install many kinds of cylindrical cutter, disc cutter, form cutter, end milling cutter and so on,

5. optional accessories as dividing head, rotary table, machine vice,milling chuck, Digital readout, can make such machine more functional.

Main Usage:

6. Suitable for machining all parts plane, inclined plane, groove, hole,keyway, etc,

7. for machinery manufacturing, mould, apparatus, instrument, car and motor car.

Main Technical Data

SPECIFICATIONS	UNIT	XL5032	XL5032	XL5032CL
Tablesize	mm	320×1325	320×1325	320×1600
T-slots (NO./Width/Pitch)	mm	3/18/70	3/18/70	3/18/70
Longitudinal travel	mm	750	1100	1300
Cross travel	mm	320	320	320
Vertical travel	rpm	460	460	450
Table feed. (X, Y, Z)	mm/min	30~750, 20~500, 15~375	30~750, 20~500, 15~375	30~750, 20~500, 15~375
Tablerapid speed (X/Y/Z)	mm/min	1200/800/600	1200/800/600	1200/800/600
Spindle pore	mm	290	290	290
Spindle taper		7:24 ISO50	7:24 ISO50	7:24 ISO50
Spindle speed range	r/min	50~1475	50~1475	50~1475
Spindle speed step	steps	12	12	12
Spindle travel	mm	70	70	70
Max. swivel angle of vertical milling head		±30°	±30°	±30°
Distance between spindle nose and table surface	mm	50~510	50~510	50~510
Distance between spindle axis and column guideway	mm	378	378	378
30 to feed Ac servo motor torque	N.m	10	10	10
Main motor Power	kW	5.5	5.5	5.5
Overall dimensions	mm	2294×1770×1900	2294×2050×1900	2294×1770×2084
Net weight	kg	2900/3200	3000/3300	3000/3300
