Catalogue of DL Series heavy duty slant bed cnc turning lathe
- Dalian China
- T/T Credit Card PayPal
You May Like
Product Details
Condition | New | Type | Other, slant bed cnc lathe | |
CNC or Not | CNC | Automatic Grade | Automatic | |
Max. Swing Diameter | 1000mm | Place of Origin | Liaoning, China | |
Brand Name | DALIAN | Model Number | DL20M DL25M DL30M DL32M DL40 slant bed cnc lathe | |
Voltage | 3Phx220V 380V 400V 415V 440V 480V, 50/60Hz | Power(W) | 11/22/30kW | |
Dimension(L*W*H) | Depends | Weight | Depends | |
Certification | CE Certificate; ISO9001:2008; GB/T19001:2008 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
DL Series slant bed cnc lathe Technical Parameter
1. Rigid cast-iron structure hardened (50-52HRC) and ground guarantee high precision and stability;
2. The machine bed is made of heat stabilized cast-iron;
3. A wide range of options and accessories allow the machine to be highly customized for very accurate and reliable machining;
4. Various configuration are available with spindles from ASA 5" to ASA 15",power up to 30kW and tuming length up to 3000mm;
Standard Configuration
5. 45° inclined bed split and linear guide way;
6. spindle stepless speed;
7. 12-station hydraulic turret;
8. 8″ hydraulic Solid chuck and Hydraulic tailstock;
9. Lateral waste device and Closed-end protection;
Item | DL15 | DL20 | DL20M | DL25M | DL30M | DL32M | DL40 | DL50 |
Swing over bed mm) | ¢450 | ¢460 | ¢460 | ¢520 | ¢625 | ¢680 | ¢800 | ¢1000 |
Center distance (mm) | 320 | 600/1000 | 600/1000 | 1000/1500 | 1000/1500 | 1000/2000 | 2000/2500/3000 | 2000/3000/4000 |
Max. turning diameter(Shafts/ Discs)(mm) | ¢250/300 | ¢260/380 | ¢260/380 | ¢310/500 | ¢310/600 | ¢400/630 | ¢550/750 | ¢800/1000 |
Guide way type | linear | linear | linear | box-type | linear | box-type | box-type | box-type |
Chuck size | 6" | 8" | 8" | 10" | 12" | 15" | 15" | 15" |
Spindle nose | ISO A2-5 | ISO A2-6 | ISO A2-8 | ISO A2-8 | ISO A2-8 | ISO A2-11 | ISO A2-11 | ISO A2-15 |
Spindle speed (rpm) | 50~5000 | 40~4000 | 45~4500 | 35~3500 | 30~3000 | 20~2000 | 20~2000 | 50~1200 |
Main spindle motor power(S6)(kW) | 5.5/(7.5) | 11(15) | 11(15) | 18.522 | 15(18.5) | 22(30) | 22(30) | 22(30) |
Spindle bore diameter (mm) | ¢70 | ¢70 | ¢76 | ¢88 | ¢88 | ¢100 | ¢100 | ¢100 |
X-axis travel (mm) | 150 | 220 | 265 | 260 | 325 | 375 | 375 | 500 |
Z-axis travel (mm) | 320 | 540/1000 | 700/1040 | 1100/1600 | 1110 | 1030/2030 | 2160/2660/3160 | 2160/3160/4060 |
X-axis rapid traverse(m/min) | 20 | 12 | 20 | 12 | 24 | 13 | 12 | 12 |
Z-axis rapid traverse(m/min) | 20 | 16 | 20 | 12 | 24 | 13 | 16 | 12 |
Positioning accuracy(mm) | X 0.016 Z 0.020 | X 0.016 Z 0.025 | X0.010 Z0.012 | X 0.016 Z 0.025 | X 0.019 Z 0.032 | X 0.019 Z0.032 | X 0.019 Z 0.040 | X 0.019 Z 0.040 |
Repeat positioning accuracy(mm) | X 0.007 Z 0.008 | X 0.007 Z 0.010 | X 0.0040 Z 0.006 | X 0.0070 Z 0.010 | X 0.0010 Z 0.013 | X 0.0010 Z 0.013 | X 0.0012 Z 0.015 | X 0.0012 Z 0.020 |
Turret: number of stations | 8 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
Tool size (mm) | 20×20 | 25×25 | 25×25 | 25×25 | 25×25 | 32×25 | 32×25 | 32×25 |
