DL25Mx1500 CE slant bed cnc lathe for sale

FOB Price

US$ 80,150 - 87,470 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, slant bed at 45°
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	520mm	Place of Origin	Liaoning, China
Brand Name	DALIAN	Model Number	DL25Mx1500 slant bed cnc lathe
Voltage	3Phx220V 380V 400V 415V 440V 480V, 50/60Hz	Power(W)	18.5/22kW
Dimension(LWH)	4934x1830x1977mm	Weight	8300kgs
Certification	CE; ISO9001:2008; GB/T19001:2008	After-sales Service Provided	Engineers available to service machinery overseas

DL25Mx1500 CNC Slant Bed Lathe Parameter

The machines contain ISO 9001 certificates, National Free-inspection Product

Machine Features

1. Rigid cast-iron structure hardened (50-52HRC) and ground guarantee high precision and stability;

2. The machine bed is made of heat stabilized cast-iron;

3. A wide range of options and accessories allow the machine to be highly customized for very accurate and reliable machining;

4. Various configuration are available with spindles from ASA 5" to ASA 15",power up to 30kW and tuming length up to 3000mm;

5. CE standard and CE Certificate;

Standard Configuration

6. 45° inclined bed split and box guide way;

7. spindle stepless speed;

8. 12-station hydraulic turret;

9. 8″ hydraulic Solid chuck and Hydraulic tailstock;

10. Lateral waste device and Closed-end protection;

Detailed Photos

Main Technical Data

Specifications	Unit	Parameter
Swing over bed	mm	Φ520
Center distance	mm	1500
Max. turning diameter r(Shafts / Discs)	mm	Φ310/Φ500
Guide way type	mm	box-type
Chuck size		10"
Spindle nose		ISO A2-8
Spindle speed	rpm	35~3500
Main spindle motor power (S6)	kW	18.5(22)
Spindle bore diameter	mm	Φ87
Max. bar diameter		Φ74 (hollow spindle and cylinder, optional)
X-axis travel	mm	260
Z-axis travel	mm	1100
X-axis rapid traverse	m/min	12
Z-axis rapid traverse	m/min	12
Positioning accuracy	mm	(X)0.016 (Z)0.025
Repeat positioning accuracy	m/min	(X)0.007 (Z)0.010
Turret: number of stations	mm	12
Tool size	mm	25×25
Tailstock quill diameter	mm	Φ100
Tailstock quill travel	mm	139
Tailstock taper	MT	5
Machine size: L×W×H	mm	4934×1830×1977
Net weight	kg	8300

Machining Sample
