High Performance Pigtailed Laser Diode 1 - 20 mw 635 nm Laser Diode
- T/T L/C D/P D/A
- 7 days
You May Like
-
650nm Pigtailed laser diode with output power 1 - 20 mw for light source
-
10 - 30 mw Output Power 808nm Pigtailed Laser Diode For Light Source
-
20 - 40 mw High Power Pulsed Laser Diode 1490nm OTDR Application
-
OTDR System Coaxial Pigtail FP Pulse Cheap Laser Diode 1310nm
-
Professional 1310nm Laser Diode 2.5Gb/s bandwitdth / FP Laser Diode 60mw
-
FFTH and Digital G - PON ONU BOSA module with T1310 LD / R1490 APD-TIA
Product Details
| Place of Origin | China | |
| Model Number | 635nm laser diode |
Product Description
Certification:RoSH, ISO9001
635nm?Pigtailed?Components
Features
1. Wavelength?:?635nm(Typ.)
2. Output?power?:?1-20mW
3. Threshold?current?:?Ith=25mA(Typ.)
4. Operating?voltage?:?Vop=2.2V(Typ.)???
5. Package?:?Coaxial?Pigtail?φ6.0mm
Applications
Light?source
Absolute?Maximum?Ratings
|
Parameter |
Symbol |
Min. |
Max. |
Unit |
|
Fiber?Output?Power |
Po(CW) |
20 |
mW |
|
|
Forward?Current(LD) |
If(LD) |
200 |
mA |
|
|
Reverse?Voltage(LD) |
Vr(LD) |
2 |
V |
|
|
Forward?Current(PD) |
If(PD) |
2 |
mA |
|
|
Reverse?Voltage(PD) |
Vr(PD) |
15 |
V |
|
|
Storage?Temperature |
Tstg |
-40 |
85 |
℃ |
|
Operating?Temperature |
To |
-10 |
60 |
℃ |
|
Lead?Solder?Temperature |
- |
260 |
℃ |
|
|
Lead?Solder?Time |
- |
10 |
S |
Optical?&?Electrical?Characteristics
|
Parameter |
Symbol |
Min. |
Typical |
Max. |
Unit |
|
Output?Power |
Po |
1 |
20 |
mW |
|
|
Threshold?Current |
Ith |
25 |
30 |
mA |
|
|
Opersting?Current |
If |
40 |
140 |
mA |
|
|
Opersting?Voltage |
Vf |
2.2 |
2.5 |
V |
|
|
Monitor?Current |
Im |
100 |
500 |
uA |
|
|
Cent?Wavelength |
λc |
630 |
645 |
nm |
|
|
Spectral?Width(RMS) |
Δλ |
2 |
3 |
nm |
|
|
Spectral?Shift |
Δλ/ΔT |
0.2 |
nm/℃ |
||
|
Fiber |
SM(4um?or?9um),MM,other |
Pin?Assignment
Drawing
Order?Information
S635-XXXXX
|
S |
635 |
-X |
X |
X |
X |
X |
|
Mode |
Wavelength |
Connector |
Fiber?Type |
Pin?Type |
Pigtail?Length |
Power?Range |
|
635:635nm |
1:FC/APC 2:FC/PC 3:SC/APC 4:SC/PC 5:ST/PC |
S4:SM?4um S9:SM?9um M5:MM?50 M6:MM?62.5 |
F H |
05:0.5M 10:1. |
