professional Full - Automatic window / Door Frame Roll Forming Machine 0-15m/min
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Automatic G.i Coil Door Frame Roll Forming Machine With PLC Control Sysetm
-
Customized Carbon Steel Purlin Roll Forming Machine , 18.5KW Cold Roll Former
-
Hydraulic Cutting Carbon Steel C Purlin Roll Forming Machine With 13 Stations
-
Chains Transmission 11kw Tile Roof Panel Roll Forming Machine With 22 Stations
-
PPGI / Aluminium Roof Panel Roll Forming Machine With Universal Joint 0-30m/min
-
High speed 22KW Carbon Steel Silo Making Machine With Curving Machine
Product Details
| Brand Name | ZOOY | Place of Origin | China | |
| Model Number | ZO-DFM |
Product Description
Certification:CE
Single Side Adjustable Door Frame Roll Forming Machine For 1.2 - 2.5mm Thickness Corbon Steel, With PLC Control Sysetm
Description
Our main products include PU sandwich panel production line, PURLIN ROLL FORMING MACHINE, STEEL SILO ROLL FORMING MACHINE, guardrail roll forming machines , metal roofing /decking/cladding roll forming machines , roof tile roll forming machines ,door & window frame roll forming machines , guide rail roll forming machines, upright post roll formers, gutter machines and downspout machines , T-bar forming machines , stud and track forming machines, cable tray roll forming machines, roller shutter manufacturing lines and so on.
Composition of machine
|
Roll forming main machine |
1 unit |
|
5 TONS Un-coiler |
1 unit |
|
PLC Control panel |
2 unit |
|
Punching system |
1 unit |
|
Hydraulic station |
1 unit |
|
Hydraulic cutting device |
1 unit |
|
Safety cover device |
1 unit |
|
Manual out table |
2 unit |
Specifications ??
|
Coil Material? |
Thickness |
1.2-2.5mm ? ? ? ? ? ? ? ? |
|
Coil width |
Depend on customer’s requires |
|
|
Yield Strength |
250-350Mpa |
|
|
Material |
? ? ? ?G.i Coil or Carbon steel |
|
|
Decoiler / Uncoiler |
Coil Width??????????????????????? |
Max. 1000mm |
|
I.D |
510-610mm |
|
|
O.D |
Max. 1200mm |
|
|
Capability |
Max. 5Tons |
|
|
Decoiler type |
Manual / Hydraulic/Automatic |
|
|
Feeding & guiding |
Pinch feeding |
1?Units ( 2 Rollers ) |
|
Levelling |
5 Rollers |
|
|
Cutting device |
Cutting motion |
Hydraulic Cutting( cutting sheet after forming ) |
|
Cutting blades |
Cr12Mov with heat treatment HRC58-62 |
|
|
Length Measuring |
Automatic length measuring by encoder & PLC. |
|
|
Cutting Tolerance |
1.5mm(per 3m) |
|
|
Roll Forming?Machine |
Forming Stations |
ABOUT 24 steps |
| ? | ||
|
Roller material |
GCR15, heat treatment? |
|
|
Diameter of shaft |
80mm |
|
|
Shaft material |
High grade 45# steel |
|
|
Drive type |
Gear box driven |
|
|
Forming speed |
0-15m/min |
|
|
Main power |
15kw |
|
| ? | ||
|
Electrical control |
PLC |
PANASONIC Brand or Custom-made |
|
Inverter |
YASKAWA Brand or Custom-made |
|
|
Touch screen |
MCGS Brand?or Custom-made |
|
|
Operation type |
Touch screen & Button |
|
|
Hydraulic Station |
Hydraulic station |
Famous Chinese brand |
|
Hydraulic power |
30KW |
|
|
Runout Table |
Table type |
Simple non-power type |
|
Function |
To support the finished panels |
|
|
TOTA |
