Portable automatic Color steel stud roll forming machine 7.5kw with CE Certificate

Place of Origin

China (mainland)

Brand Name

ZOOY

Model Number:

ZO-OST

Raw Material

Color steel, galvanized steel, G.I

Certificate

CE

Warranty

1 YEAR

Roll forming main machine

1 unit

5 TONS Un-coiler

1 unit

PLC Control panel

2 unit

Hydraulic station

1 unit

cutting & Punching device

1 unit

Safety cover device

1 unit

Manual out table

2 unit

Coil Material?

Thickness

0.3-1.0 mm ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

Coil width

Depend on customer’s requires

Yield Strength

250-550Mpa

Material

Color steel, ?galvanized steel, G.I ? ? ? ? ? ?

Decoiler / Uncoiler

Coil Width???????????????????????????????

Max. 1000mm

I.D

510-610mm

O.D

Max. 1200mm

Capability

Max. 5Tons

Decoiler type

Manual / Hydraulic/Automatic

Feeding & guiding

Pinch feeding

1?Units ( 2 Rollers )

guiding

2 Rollers

Cutting device

Cutting motion

Hydraulic Cutting, following -Cutting ( cutting sheet after forming )

Cutting blades

Cr12Mov with heat treatment HRC58-62

Length Measuring

Automatic length measuring by encoder & PLC.

Cutting Tolerance

1.5mm(per 3m)

Roll Forming?Machine

Forming Stations

ABOUT 8-10 steps

Roller material

45# steel, heat treatment?????????

Diameter of shaft

65mm

Shaft material

High grade 45# steel

Drive type

Driven by motor, transmit by chain

Forming speed ? ?

0-20m/min

Main power

7.5kw

Electrical control

PLC

PANASONIC Brand or Custom-made

Inverter

YASKAWA Brand or Custom-made

Touch screen

MCGS Brand?or Custom-made

Operation type

Touch screen & Button

Hydraulic Station

Hydraulic station

Famous Chinese brand

Hydraulic power

5.5KW

Runout Table

Table type

Simple non-power type

Function

To support the finished panels

TOTAL WEIGHT
