Automatic metal Roof Tile Roll Forming Machine cold roll forming equipment

FOB Price

USD $30000$ - $50000$ / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ZOOY		Place of Origin	China
Model Number	ZO-RT1200

Delivery Time:60days after get 30% down payment
Certification:CE

Galvanized steel, Color Steel, Aluminum Sheet Roof Tile Roll Forming Machine For 0.4-0.8MM Thickness

Composition of machine

Main Specifications ??
?

Coil Material?	Thickness	0.4-0.8mm
Coil width	Depend on customer’s requires
Yield Strength	G250Mpa
Material	Galvanized steel sheet
Decoiler / Uncoiler	Coil Width????????????????	Max. 1300mm
I.D	510-610mm
O.D	Max. 1200mm
Capability	Max.?5 Tons
Decoiler type	Manual / Hydraulic/Automatic
Feeding & Leveling	Pinch feeding	1?Units (?2 Rollers )
?
Cutting device	Cutting motion	Hydraulic Cutting, post-Cutting ( cutting sheet after forming )
Cutting blades	Cr12Mov with heat treatment HRC58-62
Length Measuring	Automatic length measuring by encoder & PLC.
Cutting Tolerance	1.5mm(per 3m)
Roll Forming?Machine	Forming Stations	20 Stations

Rectifying	1 unit
Roller material	GCr15 steel, heat treatment
Diameter of shaft	80mm
Shaft material	High grade 45# steel
Drive type	Chains
Forming speed	15m/min
Main power	7.5KW
Servo motor	1 Units
Driven System	Driven by Motor	Transmission by chains
Electrical control	PLC	PANASONIC Brand or Custom-made
Inverter	YASKAWA Brand or Custom-made
Touch screen	MCGS Brand?or Custom-made
Operation type	Touch screen & Button
Hydraulic Station	Hydraulic station	Famous Chinese brand
Hydraulic power	7.5KW
Runout Table	Table type	Simple non-power type
Function	To support the finished panels
TOTAL WEIGHT	?	APRRO?8 TONS

Products Photos

Competitive Advantage:

Economical Simple Standard speed High Quality Reliable Durable Reasonable Price Good after Service 1 Year Warranty More Than 10Years Experience

.
Guarantee:
1:Guaranteed against malfunctions due to manufacturing defects for 1 year after date of purchase. Repairs will b
