Aluminum Sheet Portable Downspout Roll Forming Machine With Fly Saw Cutting

Model

Portable ;Semi-automated: length control with limit switch

Driver system

Bottom drive rollers and 11 top drive rollers for smooth

even, non-twisting drive

Hard chrome steel forming rollers

Urethane power drive system

Shear

Model cutting by Hydraulic /cutter off saw /model cutting by manual

Speed

Standard 6-8m/min.

Control

Push button and related controls

Forming

Stainless steel forming rollers

Un-coiler

Manual

Built-in

Electrical

Configured to 110 volt or 220 volt

Coil Material?

Thickness

0.3-0.8mm

Coil width

Depend on customer’s requires

Yield Strength

G250Mpa

Material

Galvanized sheet,?steel sheet,Aluminum sheet

Decoiler / Uncoiler

Coil Width??????

Max. 1300mm

I.D

410-520mm

O.D

Max. 1200mm

Capability

Max.?3Tons

Decoiler type

Manual / Hydraulic/Automatic

Feeding & Leveling

Pinch feeding

1?Units (?2 Rollers )

Cutting device

Cutting motion

Hydraulic Cutting/Manual Model Cutting/Fly Saw Cutting;?post-Cutting ( cutting sheet after forming )

Cutting blades

Cr12Mov with heat treatment HRC58-62

Length Measuring

Automatic length measuring by encoder & PLC.

Cutting Tolerance

1.5mm(per 3m)

Roll Forming?Machine

Forming Stations

11 Stations

Rectifying

1 unit

Roller material

GCr15 steel, heat treatment

Diameter of shaft

60mm

Shaft material

High grade 45# steel

Drive type

Chains

Forming speed

6m/min

Main power

3.0KW

Servo motor

1 Units

Driven System

Transmission by chains

Electrical control

PLC

/

Inverter

YASKAWA Brand or Custom-made

Touch screen

/

Operation type

Touch screen & Button

Hydraulic Station

Hydraulic station

Famous Chinese brand

Hydraulic power

3.0kw

Runout Table

Table type

Simple non-power type

Function

To support the finished panels

TOTAL WEIGHT

APRRO?2
