Automatic galvanized steel stud roll forming machine Thickness 0.3 - 1.5mm
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Omega Sheet Stud And Track Roll Forming Machine For Furring Profiles
-
Full - Automatic Furring Stud And Track Roll Forming Machine with Following Ctting
-
High Speed Durable Steel Cold Roll Forming Equipment For C / Z Purlin 0-15m/min
-
Durable steel Cee / Zee Purlin Roll Forming Machine With Full - Control System
-
Automatic metal Roof Tile Roll Forming Machine cold roll forming equipment
-
Roof Tile Roll Forming Machine 0.4-0.8mm Thickness, Color Coated Aluminum Sheet
Product Details
| Brand Name | ZOOY | Place of Origin | China | |
| Model Number | ZO-CD&UD |
Product Description
Certification:CE
Following Cutting, CD & UD Stud Roll Forming Machine For Coil Sheet Thickness 0.3 - 1.5mm
WUXI ZOOY MACHINERY CO.,LTD main products include PU sandwich panel production line, PURLIN ROLL FORMING MACHINE, STEEL SILO ROLL FORMING MACHINE, guardrail roll forming machines , metal roofing /decking/cladding roll forming machines , roof tile roll forming machines ,door & window frame roll forming machines , guide rail roll forming machines, upright post roll formers, gutter machines and downspout machines , T-bar forming machines , stud and track forming machines, cable tray roll forming machines, roller shutter manufacturing lines and so on.
Main Specifications ??
?
|
Coil Material? |
Thickness |
0.3-1.0 mm ? ? ? ? ? ? ? ? ? ? ? ? |
|
|
Coil width |
Depend on customer’s requires |
||
|
Yield Strength |
250-550Mpa |
||
|
Material |
Color steel, ?galvanized steel, G.I ? ? |
? | |
|
Decoiler / Uncoiler |
Coil Width??????????????????????????? |
Max. 1000mm |
|
|
I.D |
510-610mm |
||
|
O.D |
Max. 1200mm |
||
|
Capability |
Max. 5Tons |
||
|
Decoiler type |
Manual / Hydraulic/Automatic |
||
|
Feeding & guiding |
Pinch feeding |
1?Units ( 2 Rollers ) |
|
|
guiding |
2 Rollers |
||
|
Cutting device |
Cutting motion |
Hydraulic Cutting, following -Cutting ( cutting sheet after forming ) |
|
|
Cutting blades |
Cr12Mov with heat treatment HRC58-62 |
||
|
Length Measuring |
Automatic length measuring by encoder & PLC. |
||
|
Cutting Tolerance |
1.5mm(per 3m) |
||
|
Roll Forming?Machine |
Forming Stations |
ABOUT 8-10 steps |
|
| ? | |||
|
Roller material |
45# steel, heat treatment????? |
||
|
Diameter of shaft |
65mm |
||
|
Shaft material |
High grade 45# steel |
||
|
Drive type |
Gear box driven |
||
|
Forming speed |
0-45m/min |
||
|
Main power |
11kw |
||
| ? | |||
|
Electrical control |
PLC |
PANASONIC Brand or Custom-made |
|
|
Inverter |
YASKAWA Brand or Custom-made |
||
|
Touch screen |
MCGS Brand?or Custom-made |
||
|
Operation type |
Touch screen & Button |
||
|
Hydraulic Station |
Hydraulic station |
Famous Chinese brand |
|
|
Hydraulic power |
7.5KW |
||
|
Runout Table |
Table type |
Simple non-power type |
|
|
Function |
To support the finished panels |
||
|
TOTAL WEIGHT |
APRRO 7TONS |
The type pursues board (basis on customer’s require to design)
Products Photos
