High Speed CD & UD Stud Roll Forming Machine 11kw With Gear Box Driven

FOB Price

USD $60000$ - $100000$ / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ZOOY		Place of Origin	China
Model Number	ZO-CD&UD

Delivery Time:65days after get 30% down payment
Certification:CE

High Speed CD & UD Stud Roll Forming Machine With 11kw Motor Power, Gear Box Driven

Composition of machine

Main Specifications ??
?

Coil Material?	Thickness	0.3-1.0 mm ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?
Coil width	Depend on customer’s requires
Yield Strength	250-550Mpa
Material	Color steel, ?galvanized steel, G.I ? ? ? ? ? ?	?
Decoiler / Uncoiler	Coil Width???????????????????????????????	Max. 1000mm
I.D	510-610mm
O.D	Max. 1200mm
Capability	Max. 5Tons
Decoiler type	Manual / Hydraulic/Automatic
Feeding & guiding	Pinch feeding	1?Units ( 2 Rollers )
guiding	2 Rollers
Cutting device	Cutting motion	Hydraulic Cutting, following -Cutting ( cutting sheet after forming )
Cutting blades	Cr12Mov with heat treatment HRC58-62
Length Measuring	Automatic length measuring by encoder & PLC.
Cutting Tolerance	1.5mm(per 3m)
Roll Forming?Machine	Forming Stations	ABOUT 8-10 steps
?
Roller material	45# steel, heat treatment?????????
Diameter of shaft	65mm
Shaft material	High grade 45# steel
Drive type	Gear box driven
Forming speed ? ?	0-45m/min
Main power	11kw
?
Electrical control	PLC	PANASONIC Brand or Custom-made
Inverter	YASKAWA Brand or Custom-made
Touch screen	MCGS Brand?or Custom-made
Operation type	Touch screen & Button
Hydraulic Station	Hydraulic station	Famous Chinese brand
Hydraulic power	7.5KW
Runout Table	Table type	Simple non-power type
Function	To support the finished panels
TOTAL WEIGHT
