custom galvanized steel Wall PU Sandwich Panel Machine 0.3-0.8mm Thickness

FOB Price

US$ 150000$ - 400000$ / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ZOOY		Place of Origin	China
Model Number	ZO-PU600

Product Description

Delivery Time:100days after get 30% down payment
Certification:CE

Ceiling Sandwich Panel, Roofing Sandwich Panel, Wall Sandwich Panel Of PU Foaming Production Line

Description

1.This production line is a kind of specialized equipment for producing sandwich panel with the middle layer of anti-combustion polyurethane and with roof(OR wall/ceiling) forming panel as the top face layer, aluminum foil as the bottom face layer. The sandwich panel is 18 mm in thickness, max1000mm in width, length determined by the customer. The sandwich panel is mainly used as keeping warm for wall and roof . Different insulating panels with other soft facing layers could also be produced on the line.

2.The operation principle of this line is as follows: raw materials of rigid-foam are delivered into the mixing head through the metering pump on the injection machine and then injected onto the bottom facing sheet going to conveyors along with the top superficial sheet. Between the upper and lower conveyors, the liquid materials are hardened into shape,after all for above actions are completed, by an automatic tracking cutting mechanism, cut into segments according to the preset length.

Main Specifications ??
?

Coil Material?	Thickness	0.3-0.8mm
Coil width	Depend on customer’s requires
Yield Strength	250-550Mpa
Material	Color steel, ?galvanized steel
Decoiler / Uncoiler	Coil Width???????????????	Max. 1250mm
I.D	510-610mm
O.D	Max. 1300mm
Capability	Max. 8Tons
Decoiler type	Manual / Hydraulic/Automatic
Feeding & guiding	Pinch feeding	1?Units ( 2 Rollers )
guiding	2 Rollers
Cutting device	Cutting motion	Cutting adopts tracking cutting
?and saw (or fly saw) of the cutting machine can move transversely 1500mm, Cutting machine moves longitudinally and transversely along the slide way
Cutting machine adopts one-side blade band saw manner, cutting and revolving after cutting. The cutting saw can revolve, so cutting in two directions is realizable
Length Measuring	?BY encoder
Cutting Tolerance	1.5mm(per 3m)
PU sandwich panel	thickness	15-40
Standard Sandwich Panel Size	max1100mm x 4000mm(Width x Length)
Linear Speed of production	2-5 m/min
Reciprocating times of injection head per minute	<60
Control system	Production type: totally continuous production with PLC controlling
Roll Forming?Machine	Forming Stations	ABOUT 18-24steps
Roller material	45# steel, heat treatment
Diameter of shaft	75mm
Shaft material	High grade 45# steel
Drive type	By chains
Forming speed	0-15m/min
Main power	7.5kw
Electrical control	PLC	PANASONIC Brand or Custom-made
Inverter	YASKAWA Brand or Custom-made
Touch screen	MCGS Brand?or Custom-made
Operation type	Touch screen & Button
Runout Tab
