P16 Rental Stage Background LED Screen Curtain , Outdoor Lightweight
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
P10 RGB SMD3535 Stage Background LED Screen Curtain For Celebration Event
-
1R1G1B SMD 3 In 1 P7.62 Stage Background LED Screen Rental For Show Advertising
-
High Resolution P6 Stage Background LED Display Full Color , SMD3528
-
P10 RGB SMD3535 Stage LED Display Curtain For Celebration Event
-
1R1G1B P15mm Stage Background LED Screen Rental , Outdoor Lightweight
-
P6mm SMD3528 Stage Background LED Screen Indoor With High Refresh Rate
Product Details
Brand Name | Newstar-LED | Place of Origin | China | |
Model Number | WS15 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Lightweight :< 8.5KG/panel. Ultra thin: 95mm thickness
2. High brightness: >7000cd/㎡
3. Waterproof Level: IP65(Front Side), IP54 (Back Side)
4. CE,CCC,RoHS,UL,ISO9001
5.?Cabinet connection angle can be adjusted by -15 degree to +15 degree.
6.?Made by excellent aluminum material
P16?Rental?Stage?LED?Display?Curtain?,?Outdoor?Lightweight
Description:
1. Light Weight & Pretty Thin
Made by excellent aluminum material, each panel only weights 8.5 KG which makes installation job and
delivery be much more comfortable and convenient. Pretty thin thickness 95m m not only saves delivery
space but also saves installation space.
2. High brightness & Waterproof
Brightness up to 7000nits, IP65 waterproof level. It provides a perfect solution for outdoor stage use.
3. Angle Adjustment?
Cabinet connection angle can be adjusted by -15 degree to +15 degree.?This allows you can shape arc
shapes.
4. Fast Lock System & Natural Cooling System Design
Fast lock system enables installation and dismantle to be much faster: an average worker can finish 50- 70
panels per hour. Natural cool system design results in good heat dissipation and less power consuming.
Applications:
Rental, Stage, Events, Show, Exhibition, Entertainment, Concerts
Specifications:
1. WS15 Technical Parameter? ? ?
Model No. |
WS15 |
Pixel Pitch |
15.625mm |
Module Size |
500mm*62.5mm |
Module Resolution (W*H) |
32 dots*4 dots |
Pixel Density |
4096 dots/ ㎡ |
LED Type |
SMD 3535 |
Pixel Configuration |
1R1G1B |
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
Drive Mode |
Dynamic 1/4 Duty Constant Current |
Cabinet Size |
500×500×95mm |
Cabinet Resolution |
32dots×32dots |
Brightness |
≥7000cd/㎡ |
Contrast |
≥4000:1 |
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
Best Viewing Distance |
7m-300m |
Grey Scale |
10bits/1024levels |
Color Capability |
16777216 |
Color Temperature |
5000-9300K |
Maximum Power Consumption |
1500 W/m2 |
Average Power Consumption |
700 W/m2 |
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
Frame Frequency |
60-85 HZ |
Refresh Frequency |
240 - 1000HZ |
Brightness Correction |
Pixel, Module, Cabinet Correction |
Operating Temperature |
-40~+65℃ |
Operating Humidity |
10-90% RH |
LED Lifespan |
100,000 hours |
MTBF |
≥50,000 hours |
Comp |
