Stage Background Led Screen p4 Led Curtain Display Ultra Clear Full Color Led Screen For Concert
- T/T L/C D/P D/A
- 7 days
You May Like
-
Front Opening P20 Outdoor Front Service LED Display For Billboard
-
Lightweight Rental P15 Transparent LED Screen Curtain For Stage
-
Outdoor IP65 P12 Transparent LED Screen , Ultra Thin LED Display
-
P10 Lightweight Outdoor Transparent LED Screen Curtain For Events
-
P12 Outdoor Transparent LED Screen , SMD 3535 Curtain LED Display
-
P7 Waterproof Outdoor Transparent LED Screen Curtain For Show
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | LS-4 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Stage background P4?LED Curtain Display Ultra clear full color led screen for concert
Quick Detail:
1. Unequalled brightness & extreme viewing angles
2. Slim, light-weight, modular design
3. Flexible shape and design
4. Accurate color uniformity and smoother, flicker-free video
5. Ultimate picture quality, longevity and low cost of ownership
6.??Waterproof Level: ?IP31?
Description:
1. Combining several global leading display board control technologies, such as grey?level code
technology, brightness control technology, and nonlinearly rectifying?technology
2. Modularization, high resolution and high contrast design, vivid dynamic display
3. Arbitrarily exchanging the display or displaying synchronized video
4. Long lifespan, can reach more than 100,000 hours, while the power consumption?is lower than one tenth
of lamp or neon
5. Economical maintenance and cost saving
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station,schools,telecommunications,customs,stadiums,studio,shopping
malls, railways, airports, harbors, etc;
?
Specifications:
1. Indoor LED Display Technical Parameter
|
Model No. |
LS-4 |
|
Pixel Pitch |
4mm |
|
Module Size |
288*288mm |
|
Module Resolution(pixels) |
72*72 |
|
Panel Size |
576mm×576mm |
|
Panel Resolution(pixels) |
144 × 144 |
|
Pixel Configuration(RGB) |
1R1G1B |
|
Pixel Density(pixels/m2) |
62,500 |
|
Brightness(cdm2) |
>1,500 |
|
Best Viewing Distance(m) |
6-100 |
|
Max.Power Consumption(W/m2) |
840 |
|
Waterproof Level |
IP31 |
|
Wavelength |
R 620-625 G 520-525 B 470-475 |
|
LED SPEC |
2020 |
|
Viewing Angle |
140°(H)/140°(V) |
|
Operating Temperature |
–40~60°C |
|
Video Frame Rate(Hz) |
≥60HZ |
|
Display Refresh Rate(Hz) |
≥300HZ |
|
Grey Level(colors) |
16.7million |
|
MTBF |
≥50,000 hours |
|
Lifespan |
≥100,000Hours |
|
Working Voltage |
220V±15% OR 110V±15% |
|
Drive Mode |
Constant 1/18 |
|
Graphics Card |
DVI Graphics card |
|
Video Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
|
Control System |
LINSN |
|
Software |
LED studio 10.0 |
|
Installation |
Wall mount, hung and stand structure |
2. Indoor LED Display Module
|
Dimensions (w x h) |
288mm x 288mm |
Resolution (w x h) |
72 x 72 |
|
Pixel pitch |
4mm |
Pixel Density |
62,500/㎡ |
|
Pixel Configration |
1R1G1B 3 IN 1 |
LED Type |
SMD 2020 |
3. Indoor LED Di
