Front Opening P16 Front Service LED Display Advertising , 256mm * 256mm

Model ?No.

NS-OR-DD-P16

Pixel Pitch?

16mm

Module Size

256mm×256mm

Module Resolution(dots)

16*16

Panel Size

1024mm×768mm

Panel Resolution(dots)

64×48

Pixel Configuration(RGB)

1R1G1B

Pixel Density(dots/m2)

3906

Brightness(cd/m2)

≥ 8000

Best Viewing Distance(m)

15-300

Max. Power Consumption(W/m2)

1000

Drive? Mode

Static

Wavelength

R? 620-625? G 520-525 B 470-475

Viewing??? Angle

110°(H)/45°(V)?

Operating?? Temperature

–20~60°C?

Video Frame Rate(Hz)

≥60HZ

Display? Refresh Rate(Hz)

≥300HZ

Grey? Level(colors)

16.7million

Lifespan

≥100,000 hours

Working Voltage

220V±15% OR 110V±15%

Video Signal Input

RF,S-Video, RGB,RGBHV,YUV,YC,COMPOSITION

Control System

LINSN OR? DB-STAR

Module Size (W*H)

256mm*256mm

Pixel Configuration

1R1G1B

Pixel Pitch

16mm

? ? ?Resolution (W*H)

16 dots*16 dots

Pixel Density

3906 dots/㎡

LED Type

3mm Oval Lamp

Cabinet Size (W*H)

1024mm*768mm

Module Qty

12 pcs

? Cabinet Resolution (W*H)

96 dots*64 dots

Cabinet Pixel

6144

Weight
