P6.25 Light Weights Die-Casting LED Display Indoor For Airports , Harbors

Model No.

NS-IR-DS-P6.25

Pixel Pitch

6.25mm

Module Size

250*250mm

Module Resolution(pixels)

32*32

Panel Size

500mm×500mm

Panel Resolution(pixels)

80×80

Pixel Configuration(RGB)

1R1G1B

Pixel Density(pixels/m2)

25600

Brightness(cdm2)

2000

Best Viewing Distance(m)

6-100

Max.Power Consumption(W/m2)

1350

Waterproof Level

IP21

Wavelength

R 620-625 G 520-525 B 470-475

LED SPEC

3528

Viewing Angle

140°(H)/60°(V)

Operating Tempreture

–20~50°C

Video Frame Rate(Hz)

≥60HZ

Display Refresh Rate(Hz)

≥300HZ

Grey Level(colors)

16.7million

MTBF

≥50000 hours

Lifespan

≥100000Hours

Working Voltage

220V±15% OR 110V±15%

Drive Mode

Constant 1/10

Graphics Card

DVI Graphics card

Video Signal

RF, S-Video, RGB, RGBHV, YUV, YC, etc.

Control System

LINSN

Software

LED studio 10.0

Installation

Wall mount, hung and stand structure

Dimensions (w x h)

250mmx250mm

Resolution (w x h)

40 x 40

Pixel pitch

6.25mm

Pixel Density
