Home > Products > Die-Casting LED Display > P5.33 RGB Die-Casting LED Display ,IP21,SMD 3 In 1 LED Display Board
P5.33 RGB Die-Casting LED Display ,IP21,SMD 3 In 1 LED Display Board
- T/T L/C D/P D/A
- 7 days
You May Like
-
Flexible Advertising LED Display For Stadium Perimeter
-
1R1G1B SMD 3 In 1 P7.62 Stage Background LED Screen Indoor Rental For Show
-
High Brightness Truck Mounted LED Screen
-
Full Color Outdoor Advertising LED Display Billboard
-
Colorful P10.417 Indoor Lightweight LED Display Full Color For Wedding
-
P5.21 SMD Slim Rental LED Display , Stage Background LED Screen
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | LS-5 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
P5.33?RGB Die-Casting LED Display , IP21 SMD?3 In 1 LED Display Board
Quick Detail:
1. Brilliant contrast ratio, high resolution/high definition
2. Super light and can be installed by one person
3. Super uniformity and no mosaic
4. Available product model: P3.84, P4, P4.8,?P5.33, P6.
5.?Waterproof Level: IP21
6.?Brightness(cd/m2)>2000nit
Description:
1. Supper thin Design?
576?x 576?x 83mm per panel.
2. Fast ?and simple Assembly
No tools needed, one person can install at least 70 cabinets per hour. One person can finish the whole
process alone.
3. Light Weight?
One cabinet only weights 9?KG, 34KG for one square meter.?
4. Aluminum Die casting?Materials?
good appearance, anti-corrosiveness . 9?kg/panel,
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,
shopping malls, railways, airports, harbors, etc;
Specifications:
1. Indoor LED Display Technical Parameter? ? ?
|
Model No. |
LS-5 |
|
Pixel Pitch |
5.33mm |
|
Module Size |
288*288mm |
|
Module Resolution(pixels) |
54*54 |
|
Panel Size |
576mm×576mm |
|
Panel Resolution(pixels) |
108×108 |
|
Pixel Configuration(RGB) |
1R1G1B |
|
Pixel Density(pixels/m2) |
35,200 |
|
Brightness(cd/m2) |
2,000 |
|
Best Viewing Distance(m) |
5-100 |
|
Max.Power Consumption(W/m2) |
900 |
|
Waterproof Level |
IP21 |
|
Wavelength |
R 620-625 G 520-525 B 470-475 |
|
LED SPEC |
3528 |
|
Viewing Angle |
140°(H)/140°(V) |
|
Operating Temperature |
–40~60°C |
|
Video Frame Rate(Hz) |
≥60HZ |
|
Display Refresh Rate(Hz) |
≥300HZ |
|
Grey Level(colors) |
16.7million |
|
MTBF |
≥50,000 hours |
|
Lifespan |
≥100,000Hours |
|
Working Voltage |
220V±15% OR 110V±15% |
|
Drive Mode |
Constant 1/9 |
|
Graphics Card |
DVI Graphics card |
|
Video Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
|
Control System |
LINSN |
|
Software |
LED studio 10.0 |
|
Installation |
Wall mount, hung and stand structure |
2. Indoor LED Display Module? ? ?
|
Dimensions (w x h) |
288mmx288mm |
Resolution (w x h) |
54 x 54 |
|
Pixel pitch |
5.33mm |
Pixel Density |
35,200/㎡ |
|
Pixel Configuration |
1R1G1B 3 IN 1 |
LED Type |
3528?LED |
3. Indoor LED Display Cabinet
|
Dimensions(w x h x d)(mm) |
576x576x83 |
Module Quantity |
