P5.21 3 In 1 RGB Slim Led Display Boards Indoor For Disco , Bar
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
HD P4.46 3 In 1 Indoor Rental LED Display Advertising For Mobile Media
-
HD P3.91 SMD3528 Die-Casting LED Display , Ultra Thin LED Display
-
Super Thin SMD P5.21mm Lightweight LED Display With High Definition
-
3.91mm Hanging Lightweight LED Display , Ultra Thin LED Screen
-
IP65 1R1G1B P15 Lightweight LED Screen For Entertainment , Wedding
-
P5.33 RGB Die-Casting LED Display ,IP21,SMD 3 In 1 LED Display Board
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | LS-5 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Brilliant contrast ratio, high resolution/high definition
2. Super light and can be installed by one person
3. Super uniformity and no mosaic
4. Available Product Models: P3.91, P4.46, P5.21, P6.25.
5.?Waterproof Level: IP21
6.?Brightness(cd/m2)>2000nit
P5.21?3?In?1?RGB?Slim?Led?Display?Boards?Indoor?For?Disco?,?Bar
Description:
1. Supper thin Design?
500 x 500 x 83mm per panel.
2. Fast ?and simple Assembly
No tools needed, one person can install at least 70 cabinets per hour. One person can finish the whole
process alone.
3. Light Weight?
One Cabinet only weights 8 KG, 32KG for one square meter.?
4. Aluminum Materials?
good appearance, anti-corrosiveness . 8 kg/panel,
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,
shopping malls, railways, airports, harbors, etc;
Specifications:
1. Indoor LED Display Technical Parameter? ? ?
|
Model No. |
LS5 |
|
Pixel Pitch |
5.21mm |
|
Module Size |
250*250mm |
|
Module Resolution(pixels) |
48*48 |
|
Panel Size |
500mm×500mm |
|
Panel Resolution(pixels) |
96×96 |
|
Pixel Configuration(RGB) |
1R1G1B |
|
Pixel Density(pixels/m2) |
36864 |
|
Brightness(cd/m2) |
2000 |
|
Best Viewing Distance(m) |
6-100 |
|
Max.Power Consumption(W/m2) |
1350 |
|
Waterproof Level |
IP21 |
|
Wavelength |
R 620-625 G 520-525 B 470-475 |
|
LED SPEC |
2020 |
|
Viewing Angle |
140°(H)/60°(V) |
|
Operating Temperature |
–20~50°C |
|
Video Frame Rate(Hz) |
≥60HZ |
|
Display Refresh Rate(Hz) |
≥300HZ |
|
Grey Level(colors) |
16.7million |
|
MTBF |
≥50000 hours |
|
Lifespan |
≥100000Hours |
|
Working Voltage |
220V±15% OR 110V±15% |
|
Drive Mode |
Constant 1/10 |
|
Graphics Card |
DVI Graphics card |
|
Video Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
|
Control System |
LINSN |
|
Software |
LED studio 10.0 |
|
Installation |
Wall mount, hung and stand structure |
2. Indoor LED Display Module? ?
|
Dimensions (w x h) |
250mmx250mm |
Resolution (w x h) |
48 x 48 |
|
Pixel pitch |
5.21mm |
