IP65 1R1G1B P15 Lightweight LED Screen For Entertainment , Wedding

Brightness

≥5000 nit

Color temperature

6500/9000 K

Viewing angle-H

140 (+708-70) deg.

Viewing angle-V

140 (+708-70) deg.

Cabinet weight

8 kg

Cabinet size (W×H×D)

500×1000×95 mm

Cabinet area

0.5 sqm.

Cabinet material

Aluminum

Ingress protection (Front/Rear)

IP65/IP54

Operating temperature

–20~+60 degree

Operating humidity

10%~ 90%

Pixel configuration

1R1G1B

Pixel pitch

15.625 mm

Module size

250x250 mm

Pixel matrix per module

24x24 dots

Pixel matrix per cabinet

48x96 dots

Pixels per cabinet

4608 dots

Pixels per sq.m.

9216 dots

Minimum viewing distance

10 m

Gray scale

4096 level

Brightness control

256 level

Refresh frequency

>1000 Hz

Driving mode

1/6 scan constant current driving

Input voltage (AC)

100 ~ 240 V

Input power frequency

50 or 60 Hz

Power consumption per sq.m. (max/avg)

800/300 W

Blind spot rate

<1/10000

Lifetime at 50% brightness

100000 hours

Red wavelength (Typical)

623 nm

Green wavelength (Typical)

523 nm

Blue wavelength (Typical)

475 nm

Signal input format
(with video processor)

AV, S-Video, VGA, DVI, YPbPr,
HDM
