P10 RGB SMD3535 Stage LED Display Curtain For Celebration Event
- T/T L/C D/P D/A
- 7 days
You May Like
-
1R1G1B P15mm Stage Background LED Screen Rental , Outdoor Lightweight
-
P6mm SMD3528 Stage Background LED Screen Indoor With High Refresh Rate
-
HD P3.91mm Die-Casting LED Display Full Color With No Mosaic
-
P4.46 3 In 1 Die-Casting LED Display Indoor For Railways , Airports
-
High Resolution P7.2 Outdoor Advertising LED Display For Banks
-
P3.91 IP21 Aluminum Die-Casting LED Display , 288mm * 288mm
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | NS-IR-DS-P6 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. High brightness: >6000cd/㎡
2. Lightweight :< 8.5KG/panel. Ultra thin: 95mm thickness
3. Waterproof Level: IP65(Front Side), IP54 (Back Side)
4. CE,CCC,RoHS,UL,ISO9001
5.?Cabinet connection angle can be adjusted by -15 degree to +15 degree
6.??Long lifespan> 100,000 hours
?
P10?RGB?SMD3535?Stage?LED?Display?Curtain?for?Celebration?Event
Description:
1. High brightness & Waterproof?
Brightness reaches 6000nits, IP65. It is perfect to be used for both indoor and outdoor.
2. Light Weigh & Ultra Thin
Made by high quality aluminum material, one cabinet only weights 8.5 KG. It makes installation job and
delivery more comfortable and convenient. 95 mm thickness saves not only space for delivery but also
installation.
3. Angle Adjustment?
Cabinet connection angle can be adjusted by -15 degree to +15 degree.?This allows you shape arc
shapes.
4. Fast Lock System & No Fan Design
Easy to install and dismantle: an average worker can finish 70 panels per hour. Natural cool system design
and good heat dissipation.
Applications:
Rental, Stage, Events, Show, Exhibition, Entertainment, Concerts
Specifications:
1. WS10 Technical Parameter??
|
Model No. |
WS10 |
|
Pixel Pitch |
10.417mm |
|
Module Size |
500mm*83.33mm |
|
Module Resolution (W*H) |
48 dots*8 dots |
|
Pixel Density |
9216 dots/ ㎡ |
|
LED Type |
SMD 3535 |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Dynamic 1/4 Duty Constant Current |
|
Cabinet Size |
500×500×95mm |
|
Cabinet Resolution |
48dots×48dots |
|
Brightness |
≥6000cd/㎡ |
|
Contrast |
≥2000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
7m-300m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1500 W/m2 |
|
Average Power Consumption |
700 W/m2 |
|
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
|
Frame Frequency |
60-85 HZ |
|
Refresh Frequency |
240 - 1000HZ |
|
Brightness Correction |
Pixel, Module, Cabinet Correction |
|
Operating Temperature |
-40~+65℃ |
|
Operating Humidity |
10-90% RH |
|
LED Lifespan |
100,000 hours |
|
MTBF |
≥50,000 hours |
|
Computer Operation System |
Win 98/ Win XP/ Win 2000 |
|
|
