40x90 Roof Battern Roll Forming Machine , Cold Roll Forming Equipment
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Auto Pipe Forming Machine Hydraulic Pipe Bender R30 - R500 mm Bend Radius
-
PLC Control Roll Top Ridge Roll Forming Line With Hydraulic Shear
-
Steel Seamed Pipe Forming Machine 0.6mm - 1.2mm PLC Tube Making Machine
-
5.5Kw Hydraulic Forming Machine 45# Forge Steel Roller For Facia Board
-
Colored Steel Sheet Octagonal Pipe Forming Machine , Sheet Metal Roll Former
-
Automatic Chain Drive Pipe Forming Machine 6 inch Half Round Forming Line
Product Details
| Brand Name | HRF | Place of Origin | China | |
| Model Number | HRF40x90 |
Product Description
Certification:CE
40x90 Roof Battern rollformer
Description:
Technical Parameter:
1) Suitable raw material: 0.5---0.8mm colored steel sheet or
galvanized steel(G300Mpa)
2. Main motor power:5.5Kw
3) Forming speed:10-12m/min
4) Number of roller stations: 14
5) Control system: PLC,Panasonic made in Japan
6) way of cutting:hydraulic cutting
7) Dimension of the machine: about7000mm×800mm×1200mm
10: Cut-to-length tolerance:≤±1.5mm
11) Control voltage: 380 V,50Hz,3 Ph or according to local standard
12) Shafts diameter:Ф60mm
13) Rollers manufacture:45#steel, machine tooling on the surface and polished
14) Omron encoder measures the length
15) Yaskawa inverter made in Japan
Technological Process:
Work Flow:
manual decoiler -- feeding ---- sheet forming -- hydraulic cutting? after forming -- outable
Specifications:???????????????????????????????
Drawing:
|
1 |
Material thickness |
mm |
0.5-0.8mm G350Mpa |
|
2 |
Forming speed |
m/min |
12-15 |
|
3 |
Roll station |
/ |
14 |
|
4 |
Main power |
kw |
5.5 |
|
5 |
Hydraulic? cutting ?power |
kw |
4 |
|
6 |
Control system |
/ |
PLC panasonic/omron/simens/mitsubishi |
|
7 |
Drive |
/ |
Chain drive |
|
8 |
Decoiler |
5T/manual decoiler ( coil car as option) |
