PV,Solar Application and MC3 Type Connector From REOO Solar Connector Manufacturer

Raw material

Used for

Price

Characteristic

PPO

PX9406P-7001

Junction box

Lower

Most of company use it for junction box.

PPO

540Z

Junction box

Lower

 Lower price

PPO

V0150B

Junction box

Middle

RTI higher than PX9406P

PPO

644Z

Junction box

Middle

Good quality for junction box

PA66

FR7025

Connector nut

Middle

Most of company use it for connector

PA66

FR370

Connector nut

Middle

Most of company use it for connector

PC

EXL9330

Connector house

Expensive

Top quality.

Item

RO-2 solar PV cable connector

Compatible:

MC3 Solar connector

Insulation material:

TPE/PA

Rated current :

25A

Rated voltage:

1000V

Test voltage :

6000V(50Hz,1Min)

Contact material :

Copper Tin plated

Contact resistance:

5mΩ

Degree of protection :

IP65

Safety class:

2

Flame class:

UL94-V0

Insertion force :

≤50N

Withdrawal force :

≥50N

Ambient temperature range :

-40 degree to +90 degree

Connector diameter :

4mm

Compatible cable cross sections :

solar cable 4.0mm2 and 6.0 mm2

Suitble cable :

2.5-6.0mm2 AWG 14/12/10

Be used for:

Connecting solar PV cable

characteristic

High insulation,

Fast integration

Male house

100 pcs / PE bag.

10 bag / carton,

also 1000 Pin/carton

Female house

100 pcs / PE bag.

10 bag / carton,

also 1000 Pin/carton

Measure

380*290*470 mm/carton

Net weight

34 kg / carton

Gross weight

35.5 kg / carton
