10 ports DIN-Rail Industrial Gigabit Ethernet Switch

1.Support IEEE802.3, IEEE802.3u, IEEE 802.3x, IEEE802.3z, IEEE802.3ab

2.Support 8 port 10/100/1000Base-TX and 2 port 1000Base-FX

3.Ethernet port support 10/100/1000M self-adaption

4.Support flow control, fiber port trunking and port isolation function

5.Support redundant power input (DC12~48V), reverse connection protection

6.Industrial grade design, 0-55℃ working temperature

7.IP40 protection grade, DIN-Rail mounting

8.No fan design

IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3z

Flow control: IEEE802.3x flow control, back press flow control

Switch

Properties

Transmit mode: store and forward
System exchange bandwidth: 20G
MAC address table: 8K
Memory: 1M

Electric port: 10/100/1000Base-T(X) auto speed control, Half/full duplex and MDI/MDI-X auto detect

Gigabit fiber port: 1000Base-FX, SC/ST connector optional

Twisted-pair: 100m (standard CAT5/CAT5e cable)

Multi-mode Fiber: 1310nm, 2Km

Single-mode Fiber : 1310nm, 20/40Km;1550nm, 60/80/100/120Km

Interface indicator: Link (G1~G10)

Power supply indicator: P1, P2

 Input Voltage: 12~48VDC
Type of input: 4 bit 7.62mm pitch terminal block
Support reverse connection protection
No-load consumption: 3.9W@24VDC
Full-load consumption: 8.6W@24VDC

Shell: IP40 protect grade, metal shell
Size(W×H×D): 50mm×115mm×80mm

Installation: DIN rail mounted

EMI: FCC Part 15, CISPR (EN55022) class A
EMS: EN61000-4-2 (ESD), Level 1
EN61000-4-5 (Surge), Level 1
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6

1. Industrial Ethernet Switch ES2010G-2GF(plus terminal block)  × 1
2. User manual × 1
3. Certificate of quality × 1
4. Warranty card × 1

5.DIN-Rail fittings  × 1
