8 ports DIN-Rail Industrial Ethernet Switch with 2 Gigabit SFP ports

1.Support 8 10/100M ports, and 2 gigabit Ethernet ports (SFP slots)
2.Support IEEE802.3/802.3u /802.3x
3.Support 10/100M, half/full duplex, MDI/MDI-X
4.Support broadcast storm shield
5.DC12~48V Power input
6.Industrial grade 4 design
7.IP30 protection, metal shell, DIN Rail mounted

Switch

Properties

Forward speed: 1488100pps

Maximum filter speed: 1488100pps
Transmit mode: store and forward
Backplane bandwidth: 20.0Gbps
MAC table size: 8K
Buffer size: 1M

Electrical Port: RJ45 Connector, 10/100Base-T(X) auto negotiation, full/half duplex mode, MDI/MDI-X

Gigabit SFP Port:1000Base-X, LC

Power port: 2 channel power iutput( 4 bit terminal block)

10/100Base-T(X):CAT5/CAT5e UTP(≤100m)

1000Base-X:Optical Fiber

Multi-mode:    1310nm, 2Km
Single-mode: 1310nm, 20/40/60Km
                          1550nm, 80/100/120Km

wavelength: 1310nm, 1550nm

Power input: 24VDC(12~48VDC)
Terminal block: 4 bit 7.62mm separation distance

Over voltage protection

Shell: IP40 protect grade, metal shell
Size(W×H×D): 136mm×105mm×52mm

Weight:800g

Installation: DIN rail mounted

EMI:

FCC Part 15, CISPR (EN55022) class A
EMS:

EN61000-4-2 (ESD), Leve 4
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 4
EN61000-4-5 (Surge), Level 4
EN61000-4-6 (CS), Level 3
EN61000-4-8, Level 5
Shock:

IEC 60068-2-27
Free fall:

IEC 60068-2-32
Vibration:

IEC 60068-2-6

1. Industrial Ethernet Switch IES2010-2GS (plus terminal block)  × 1
2. User manual × 1
3. Certificate of quality × 1
4. Warranty card × 1

5.DIN-Rail fittings  × 1
